Description

Vortex Viper HS-T 4-16x44m

Tree stands to mountain tops, bolt guns to ARs, the Viper HST is ideal for a wide range of shooting applications. Blending many of the best features from Vortex’s incredibly popular Viper PST and Viper HS riflescopes, the Viper HST riflescope is built on an ultra strong 30 mm, one piece aluminum tube to deliver ample windage and elevation travel and optimal adjustment. An advanced optical system, highlighted with a 4x zoom range, provides magnification versatility.

Viper HS-T 4-16x44mm Features

XD Lens Elements

Extra low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images.

XR Fully Multi Coated

Proprietary coatings increase light transmission with multiple anti reflective coatings on all air to glass surfaces.

Second Focal Plane Reticle

Scale of reticle maintains the same ideally sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.

Tube Size

30 mm diameter provides maximized internal adjustment and strength.

Single Piece Tube

Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.

Aircraft Grade Aluminum

Constructed from a solid block of aircraft grade aluminum for strength and rigidity.

Waterproof

Fogproof

Shockproof

Hard Anodized Finish

Highly durable hard coat anodization provides a low glare matte surface and helps camouflage the shooter’s position.

ArmorTek

Ultra hard, scratch resistant coating protects exterior lenses from scratches, oil and dirt.

Exposed Tactical Style Turrets

Provide fast, accurate and easily read elevation and windage adjustments.

Side Focus

Adjustment located on left side of turret housing is easily accessible from shooting position. Provides optimal image focus and parallax removal.

CRS Zero Stop

Customizable Rotational Stop (CRS) aids in return to zero after dialing temporary elevation correction.

Precision Force Spring System

Uses premium components in the erector spring system to ensure maximum repeatability and ease of adjustment.

Precision Glide Erector System

This system ensures the components in the zoom lens mechanism glide smoothly and cleanly through all magnification ranges.

MAG View Fiber Optic

Provides a highly visible reference point for the magnification setting.

Radius Bar

Fiber optic turret rotation indicator provides a highly visible and tactile point of reference for turret rotations.

Fast Focus Eyepiece

Allows quick and easy reticle focusing.


Specifications

Magnification 4-16x
Objective Lens Diameter 44 mm
Eye Relief 4.0 inches
Field of View 27.4-7.4 ft/100 yds
Tube Size 30 mm
Turret Style Tactical
Adjustment Graduation .1 MRAD
Travel Per Rotation 5 MRAD
Max Elevation Adjustment 21 MRAD
Max Windage Adjustment 21 MRAD
Parallax Setting 50 yards to infinity
Length 13.33 inches
Weight 20.8 oz










Related Items

Additional information

Weight 1.3 lbs
Vortex Reticle Option

VMR-1-MOA, VMR-1-MRAD
