AGM Anaconda TC50 336 Thermal Imaging Clip On System


Out of stock

SKU: 3093456006AN51 Categories: , ,

AGM Anaconda TC50 336

The AGM Anaconda TC50 336 Clip On TC-Micro is a compact thermal imaging clip on system. It will allow you to transform your day optic into a thermal imaging device at ease. The TC50 has a 50mm lens modification that can be used for medium range shooting. It can also be attached to up to an 8x magnification scope. The Anaconda TC-Micro is powered by two CR123 batteries that give you up to 5 hours of continuous use. There is an optional external battery pack that can increase operation time to up to 44 hours.

AGM Anaconda TC50 336 Features:

Compact and lightweight design

Easy to operate device


External power supply via micro USB

Powered with two CR123 batteries

AGM Anaconda TC50 336 Clip On Product Warranty Registration »


Detector FLIR Tau 2 336 x 256 17μm Uncooled Microbolometer
Refresh Rate 60 Hz
Resolution 336 x 256
Recognition 350yds
Detection 600yds
Lens System 50 mm; F/1.1
Optical Magnification 1x
Field of View 7.8° x 5.9°
Digital Zoom 1x, 2x, 4x
Diopter Adjustment Range -5 to +5 dpt
Focusing Range 5 m to infinity
Eye Relief 60 mm
Exit Pupil Diameter 40 mm
Display 800 x 600 pixels
Video Output PAL (768 x 574 pixels)/ NTSC (640 x 480 pixels)
Image Palettes Changeable
Remote Control Wireless (Activates and Deactivates the scope in Standby Mode)
Environment Rating Waterproof
Battery Type Two CR123A 3V Lithium batteries or two CR123 type rechargeable batteries with voltage from 3.0V to 3.7V
Battery Life (Operating) Up to 4 hr at 20°C
External Power Supply Power bank (5V) via Micro-USB port; Extended battery pack (6V) or 6V/600 mA power supply via S620 connector
Operating Temperature Range -40°C to +50°C (-40°F to +122°F)
Storage Temperature Range -50°C to +70°C -58°F to +158°F)
Interfacing Micro-USB (Power bank 5V) Universal S620 connector (Power In, Analog Video In/Out, Wi-Fi Attachment, HD Recorder, Extended Battery Pack)
Weight 0.81 kg (1.8 lbs)
Overall Dimensions 217 x 71 x 81 mm (8.5 x 2.7 x 3.1 in)
