AGM Cobra TB75-640 Thermal Imaging Bi-ocular

The AGM Cobra TB75-640 Thermal Imaging Bi-ocular is part of the most advanced thermal imaging devices currently on the market. It is built with high grade aluminum alloy making it durable and lightweight. The bi-ocular is waterproof, so it will still work well in the most challenging environments. It is built with a FLIR TAU microbolometer core and offers a variety of image palettes, making it able to adapt to any environment. The bi-ocular is powered by 2 CR123A Lithium batteries or two CR123 rechargeable batteries.

AGM Cobra TB75-640 Thermal Imaging Bi-ocular Features

Lightweight and durable design

Easy to operate device

High resolution display 800×600


Powered by two standard CR123A batteries

External power supply via micro USB

Tripod mountable

Limited 3 Year Warranty

Data Sheet

User Manual


Detector Type FLIR Tau 2 640×512
Refresh Rate 60 Hz
Start Up 3 seconds
Lens System 75 mm; F/1.0
Optical Magnification 2.6×
Field of View (H × X) 8.3° × 6.6°
Digital Zoom 2×, 4×, 8×
Diopter Adjustment Range -5 to +5 dpt
Focusing Range 5 m to infinity
Display 800×600
Video Output PAL (768×574 pixels)/ NTSC (640×480 pixels)
Temperature Imaging Palettes White Hot, Black Hot, Fusion, Rainbow, Globow, Ironbow1, Ironbow2, Sepia, Color1, Color2, Ice-Fire, Rain, and OEM
Interfacing Micro-USB (Power bank 5V) Universal S620 connector (Power In, Analog Video In/Out, Wi-Fi Attachment, HD Recorder, Extended Battery Pack)
Battery Type Two CR123A 3V Lithium Batteries or CR123 Type Rechargeable Batteries with Voltage from 3.0V to 3.7V (2)
Battery Life (Operating) Up to 4 hr (optional up to 12 hrs)
Operating Temperature Range -40°C to +50°C

(-40°F to +122°F)

Weight 1.14 kg

(2.5 lbs)

Overall Dimensions 312 x 109 x 89 mm

(12.2 x 4.2 x 3.5 in)

Package Includes Thermal imaging bi-ocular, Lens Cloth, Soft Carrying Case, User Manual
