AGM Protector TM75-384 Thermal Imaging Monocular


Out of stock

Want to be notified when this product is back in stock?

SKU: 3083451008PR71 Categories: , , Tags: , , , ,

AGM Protector TM75-384 Thermal Imaging Monocular

The AGM Protector TM75-384 is a thermal imaging monocular that is constructed of aircraft grade aluminum and magnesium alloy. This uncooled, long wave infrared, magnified thermal imaging camera is designed for fulfilling both, day and night missions, irrespective of the environment and weather factors. A variety of objective lenses (25 mm, 50 mm, 75 mm) enable the operator to use the device as both a compact, pocket sized thermal imaging monocular, or as a long range observation tool. The Protector thermal imaging monocular can be easily connected to an extended battery pack (5V), increasing operational time. Optional WiFi module for live video streaming and recording is also available.

AGM Protector TM75-384 Thermal Imaging Monocular Features

Lightweight and compact design

Superior clarity, versatility and reliability

Easy to operate control panel

High resolution display

2x and 4x digital zoom

Picture in Picture mode with 2x digital zoom

Automatic or manual (silent) calibration

Stadiametric rangefinder

Powered by two standard CR123A batteries

External power supply via micro USB

Optional external WiFi module and video recorder

Integral MIL-STD-1913 rail on unit for optional accessories

Tripod mountable

Limited 3 Year Warranty

Package Includes

Lens Cloth

Soft Carrying Case

User Manual

Data Sheet

User Manual


Detector type 17μm Uncooled Microbolometer
Refresh rate 50 Hz
Resolution 384 x 288
Lens system 75 mm; F/1.0
Optical magnification 3.75×
Field of view (H × X) 5.0° x 3.7°
Digital zoom 1×, 2×, 4×
Diopter adjustment range -5 to +5 dpt
Focusing range 10 m to infinity
Display HD Display 1024 x 768
Video/Photo Format AVI / JPG
Temperature imaging palettes 11 Image palettes
Interfacing S620 Connector (Power In, Analog Video In/Out, Digital Video Recorder)

Micro USB (External Battery Pack)

Battery Type Two CR123A 3V Lithium Batteries
Battery Life (Operating) Up to 5 hr
Power supply 5V USB / 3.6~7.2V
Operating Temperature Range -40°C to +70°C

(-40°F to +158°F)

Degree of Protection IP67
Weight 0.69 kg

(1.5 lbs)

Overall Dimensions 250 x 93 x 93 mm

(9.8 x 3.7 x 3.7 in)

Package Inludes Thermal Imaging Monocular

Lens Cloth

Soft Carrying Case

User Manual

Export Restrictions

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
