AGM Rattler TS35 384
The AGM Rattler TS35 384 Thermal Imaging Scope were designed for 24 hour use in the worst conditions. The compact thermal imaging scope has an 8x digital zoom, and a 35mm objective lens that is perfect for medium range shooting. It features a 384 x 288 thermal detector and 1024 x 768 OLED monitor, which provides clear image under the harshest environments. The rugged design of the Rattler allows it to be waterproof and shockproof. The device can be used as a thermal imaging scope or a handheld monocular. It is mainly applied to scenarios such as patrolling, and hunting.
Powered with two CR123 batteries the AGM Rattler TS35 384 gives up to 4.5 hours of continuous operation time. An external 5V power bank can be easily connected via a USB connector for a significant increase of operating time. Onboard WiFi module for live video streaming and video/images recording via application are also available. The Rattler is backed by AGM’s Limited 3 Year Warranty.
AGM Rattler TS35 384 Features
384 × 288 thermal resolution, high sensitivity detector
Image processing technology: Adaptive AGC, DDE, 3D DNR
1024 × 768 resolution 0.39 inch OLED display
8x digital zoom
Video recording and snapshot, built in EMMC (16 GB)
Supports distance measurement
Adjustable color palettes
WiFi data transmission
Waterproof, shockproof
Up to 4.5 hours continuous working
External power supply capability
Limited 3 year warranty
Specifications | ||||||
| Resolution | 384 x 288 | |||||
| Detector | 17μm, Uncooled, 50Hz | |||||
| Lens System | 35 mm; F/1.0 | |||||
| Optical Magnification | 2.14x | |||||
| Field of View | 10.0° x 8.0° | |||||
| Digital Zoom | 2x 4x 8x PIP | |||||
| Observation Distance | Max. 1235 m | |||||
| Eye Relief | 45 mm | |||||
| Display | 0.39 inch, OLED, 1024 x 768 | |||||
| Crosshair | Yes | |||||
| Hotspot | Yes | |||||
| Distance Measurement | Yes | |||||
| Scene Mode | Jungle Recognition | |||||
| Standby Mode | Yes | |||||
| Video Recording | Yes | |||||
| Picture Snapshot | Yes | |||||
| DPC | Yes | |||||
| Uniformity Correction | Auto Manual External Correction | |||||
| Storage | Built in EMMC (16GB) | |||||
| Battery Type | Two CR123 | |||||
| Battery Life (Operating, 20°C) | Up to 4.5 hr. | |||||
| External Power Supply | 5V USB | |||||
| Operating Temperature Range | -20°C to +55°C (-4°F to +131°F) | |||||
| Degree of Protection | IP67 | |||||
| Shock and Vibration | 750 g/ms | |||||
| Weight | 0.41 kg (0.91 lb) | |||||
| Overall Dimensions | 187.2 x 62.54 x 59.2 mm (7.37 x 2.46 x 2.33 in) | |||||
| Package Includes | Thermal Imaging Rifle Scope Mount USB Cable Lens Cloth Manual | |||||
