Description

AGM Rattler TS35

The AGM Rattler TS35 Thermal Imaging Scope were designed for 24 hour use in the worst conditions. The compact thermal imaging scope has an 8x digital zoom, and a 35mm objective lens that is perfect for medium range shooting. It features a 384 x 288 thermal detector and 1024 x 768 OLED monitor, which provides clear image under the harshest environments. The rugged design of the Rattler allows it to be waterproof and shockproof. The device can be used as a thermal imaging scope or a handheld monocular. It is mainly applied to scenarios such as patrolling, and hunting.

Powered with two CR123 batteries the AGM Rattler TS35 gives up to 4.5 hours of continuous operation time. An external 5V power bank can be easily connected via a USB connector for a significant increase of operating time. Onboard WiFi module for live video streaming and video/images recording via application are also available. The Rattler is backed by AGM’s Limited 3 Year Warranty.

AGM Rattler TS35 Features

384 × 288 thermal resolution, high sensitivity detector

Image processing technology: Adaptive AGC, DDE, 3D DNR

1024 × 768 resolution 0.39 inch OLED display

8x digital zoom

Video recording and snapshot, built in EMMC (16 GB)

Supports distance measurement

Adjustable color palettes

WiFi data transmission

Waterproof, shockproof

Up to 4.5 hours continuous working

External power supply capability

Limited 3 year warranty

Data Sheet

Product Manual


Specifications

Resolution 384 x 288
Detector 17μm, Uncooled, 50Hz
Lens System 35 mm; F/1.0
Optical Magnification 2.14x
Field of View 10.0° x 8.0°
Digital Zoom 2x

4x

8x

PIP

Observation Distance Max. 1235 m
Eye Relief 45 mm
Display 0.39 inch, OLED, 1024 x 768
Crosshair Yes
Hotspot Yes
Distance Measurement Yes
Scene Mode Jungle

Recognition

Standby Mode Yes
Video Recording Yes
Picture Snapshot Yes
DPC Yes
Uniformity Correction Auto

Manual

External Correction

Storage Built in EMMC

(16GB)

Battery Type Two CR123
Battery Life (Operating, 20°C) Up to 4.5 hr.
External Power Supply 5V USB
Operating Temperature Range -20°C to +55°C

(-4°F to +131°F)

Degree of Protection IP67
Shock and Vibration 750 g/ms
Weight 0.41 kg

(0.91 lb)

Overall Dimensions 187.2 x 62.54 x 59.2 mm

(7.37 x 2.46 x 2.33 in)

Package Includes Thermal Imaging Rifle Scope

Mount

USB Cable

Lens Cloth

Manual






More from AGM

Additional information

Weight .9 lbs

1 review for AGM Rattler TS35 Thermal Imaging Scope

  1. Rated 4 out of 5
    ( 1 review )

    rleventry8015 (verified owner)

    Very nice optic for the money. Image quality for a 384 scope is very good. Battery life is good as well. Ensure you you the firmware update right away, it adds two new reticles and saves the color you select for your reticle when you turn it off. Before it would always reset to white. Am able to see and identify hogs at over 300 yards on a night where conditions are favorable. AGM customer service is outstanding. This is a great first thermal scope for anyone who wants to get into night hunting.
