Bering Optics 1.4-5.6x25mm Hogster-R

The Bering Optics 1.4-5.6x25mm Hogster-R is a thermal weapon sight that was designed for the growing feral hog market. It is lightweight, compact and .308 Cal. tested. The sight comes with a tactical quick release mount that makes the mounting on any type of rifle, equipped with the Weaver rail, quick and easy. Its compactness makes it suitable for use as a handheld imager for scouting.  The sight is built with the superb Germanium optics that is paired with an advanced Vanadium Oxide (VOx) thermal core and proprietary electronics. HOGSTER-R features an intuitive, user friendly menu to customize settings to the shooter’s needs without disengaging from the target, including MIL-Dot and Crosshair reticles along with White, Black and Colored image polarization.

The scope is nitrogen purged, is waterproof, dustproof and shockproof and is action ready in any environment or light conditions, including conditions when the environmental obscurants such as smoke, dust, haze, are present. It is suitable for use in colder temperatures thanks to the unique built  retaining its own heat and keeping the cold sensitive elements warm, virtually making it a great universal choice for any demanding user.

Bering Optics 1.4-5.6x25mm Hogster-R Features

Superior for hogs and predator control at medium and long range distances

Switchable image polarity: White Hot / Black Hot / Red Hot / Colored Hot

Picture in Picture function:  2X magnified image on the top of the display

Rangefinder function to estimate distance to the animals of known size

Manual control of the image sharpness and screen brightness

Ability to save up to 4 groups of zeroing calibration data

Four reticle patterns with 4 color options for each pattern

Option to power by rechargeable 3.7V accumulators

Automatic shatter based thermal VOx core

Precise lens focusing mechanism

External power supply via a USB port

Battery status indicator

Standby mode

Video Out

Bering Optics 1.4-5.6x25mm Hogster-R Includes

HOGSTER-R VOx 384 x 288 Thermal sight

Video out or external power supply Type C USB cable

Weapon Mount

Two Lithium CR123 batteries

Front lens protective cap

Eye piece rubber eye guard

Soft Carrying Case

Lens Cleaning Cloth

Instructions manual

Video out or external power supply Type C USB cable


Specifications

Optical Magnification, x 1.4x
Digit Multiplication, X 2X

3X

4X

Objective lens system 25mmF/1.1
Angular FOV at 1.0x (horizontal x vertical), degree 14.9° x 11.2°
Eye relief, mm 40
Focus range, m 0.5 to infinity
Diopter Adjustment, D (hand held mode only) -5: +5
Reticle W/E adjustment value at a distance of 100m (110yds) 0.8″/2.04cm increment per pxl
Core resolution, px 384 x 288
Pixel pitch, µm 17
Image refresh rate, Hz 50
Thermal Sensitivity (NETD), mK <50
Display type and resolution, pxl LCOS 1280 x 960
Start up time, min., sec. 5
Animal type and size (in Length &  Height), approx., ft² Hog L16 & H9

Coyote L5 & H2

Hog L16 & H9

Coyote L5 & H2

Detection, approx., yds / m 600yds (550m)

460yds (420m)

800yds (750m)

660yds (600m)

Recognition, approx., yds / m 225yds (200m)

160yds (145m)

300yds (275m)

200yds (185m)

Dimensions with QR mount, in / mm 7.0″ x 2. 83″ x 2. 36″ (180 x 72 x 60mm)
Weight,  approx., oz/g 16.44oz (466g)
Power supply 3V CR123 (two)

3.7V rechargeable (two)

5V Type C USB port

Estimated battery life, hour up to 4
Operating temperature, typical, °F/°С -14° to +122°

-25° to +50°

Water intrusion IP67
Humidity, % up to 98%
