Description

The CTL-3420 3 Series is a feature rich 4-20×50 mm long-range rifle scope that has been specifically built from the ground up. The scopes First Focal Plane (FFP) and impressive Japanese ED glass clarity certainly makes for an unparalleled shooting experience. The custom designed MR1-MIL advanced reticle is fully illuminate, as well as offering quick hold over points for windage and elevation. The exposed .1 MIL tactical turrets provide a precise and rugged feel when dialing for the most accurate of shots. The entire Crimson Trace Scope Line offers EZ Mount Leveling Indicators for quick and exact mounting in addition to RAR Tech, Red Alignment Ring, for proper eye placement.


POWER
The 4-20×50 mm scope makes objects seem four to twenty times closer than with the naked eye, featuring a 50 mm Objective Lens.

FIRST FOCAL PLANE (FFP)
Glass etched, LR1-MIL Advanced Illuminated reticle sits in front of the magnification mechanism, scaling to provide correct ballistic hold points at any range. Numerous windage holding points allow for on the fly adjustments during ever changing environmental conditions. Premium, Fully Multi-Coated ED Glass leads to enhanced image quality across the visual spectrum.

EXPOSED TURRETS with LR1-MIL ADVANCED RETICLE

QUALITY MANUFACTURING
The single piece 30 mm Anodized Aluminum main tube is constructed to handle the most demanding environments. Waterproof and Fog proof with coated lenses to protect from scratches, oil, and debris. Nitrogen purged and O-Ring sealed.

WARRANTY
Crimson Trace’s Lifetime Protection Guaranteed Warranty and FREE Batteries for Life guarantees a lifetime of performance.


Specifications

Product
Platform
3-Series
Max Magnification20 x
Objective Lens50 mm
Focal Plane1st Focal
Plane
Tube Diameter30 mm
ReticleLR1-MIL
Illumination
Range
11 x(3x Night)
Turret
Graduations
Milliradian
(MIL)
Adjustment
Resolution
.1 MIL
Adjustment
Per Rotation
10 MIL
Elevation
Range
100 MIL
Windage Range60 MIL
Side
Parallax
Yes
Scope Length14.6 in
Scope Weight30.2 oz

Additional information

Weight2 lbs
