Holosun HE503CU-GR Elite Micro Green Dot Sight

The Holosun HE503CU-GR Elite is a new micro green dot optic equipped with a 65 MOA circle dot reticle with the option of switching to a 2MOA dot only. Holosun’s highly efficient light emitting diodes and solar panels allow solar optics to run without a battery in many lighting conditions. Additionally, the back-up battery lasts up to 5-years on the dot and up to 2 years on the circle dot. The “U” signifies a housing design that shrouds the windage and elevation turrets on two sides.

Holosun HE503CU-GR Features

Unlimited field of view

Parallax-free with unlimited eye relief

Powered by both battery and solar

Low mount and 1/3 Co-witness mount included

Product Manual


Light Source LED
Reticle 2MOA Dot
65MOA Ring
Parallax Free Yes
Eye Relief Unlimited
Magnification 1x
Multi-Coatings Yes
Battery Type CR2032
Battery Life Up to
50,000 hr
Brightness Setting 10 Daylight &
2 NV Compatible
Housing Material 6061 Aluminum
Housing Color Black
Adjustment per Click 0.5 MOA
W&E Travel Range ±50 MOA
Working Temperature -22℉;140℉
Submersion IP67
Vibration Up to
Window Size 20mm Diameter
Dimension 2.44×1.18×1.45 in
Weight 6.3 oz
Central Height 1.63 in



More from Holosun

Additional information

Weight 0.5 lbs
