InfiRay Outdoor Bolt TL35 V2 Thermal Sight

(1 customer review)


Only 2 left in stock

SKU: IRAY-TL35V2 Categories: , , Tags: , , , , ,

InfiRay Outdoor Bolt TL35 V2 Thermal Sight

The InfiRay Outdoor Bolt TL35 V2 is a thermal sight that was designed for optimal use on any platform that demands flexible mounting options and increased eye relief. In additions to the features found on the original TL35, the TL35 V2 adds several highly requested features including an AMOLED display, audio recording, and laser rangefinder connectivity via Bluetooth. The T-6061 aluminum housing allows mounting with standard 30mm rings like a traditional day scope. A 50Hz 12μm detector, HD display, and manual focus lens all team up to create an image that’s anything but traditional. The TL35 V2 features a dual battery design for 10+ hours of run time and 32GB of internal memory to keep your optic going all night. The BOLT Series was designed from the ground up for optimal use on bolt action rifles and other platforms that demand flexible mounting options with increased eye relief.

Inside of a BOLT TL35, the image from an InfiRay 50Hz 12 micron Micro II core is displayed on a crystal clear HD display. These components and InfiRay’s proprietary MATRIX III algorithm create an image technically and visually superior to optics with similar specifications. Dual internal 18650 batteries and an optional auxiliary battery provide 10+ hours of run time. The BOLT also comes standard with 16 Gb of internal memory for hours of video capture.

InfiRay Outdoor Bolt TL35 V2 Features


The BOLT features InfiRay Outdoor’s innovative new way to control a thermal optic. Unlike other thermal optics with a turret style controller on one side, the BOLT has a large and easy to find metal turret controller on top. This makes operation easier in the dark and completely ambidextrous. The turret controller also has positive and tactile clicks when twisting, and a positive click when pressing in unlike any other thermal scope on the market. Both the aesthetics and the function of the BOLT demonstrate InfiRay Outdoor’s mission to combined the traditional style and feel of a day optic and the advanced technology of thermal imaging.


The TL35 V2 features the industry leading InfiRay 12 micron Micro II core with proprietary MATRIX III image processing, but that is just where the high performance begins. Along with the best sensor and software the TL35 V2 uses a set of optics specifically designed for a 12 micron sensor and a low power consumption AMOLED HD display. Dual internal batteries power the BOLT for an incredible 10+ hours, and if you need more runtime the BOLT has an additional battery well for an off-the-shelf 18500 or 18650 battery. The BOLT also supports charging the internal batteries through a USB-C connector while in operation so you are never stuck with a dead battery.


The BOLT comes with 16gb of memory for storing 20,000 images or 24 hours of video. Captured videos with audio and images can be easily transferred to your smartphone at lightning speed via app. The WiFi mode also allows for up to 4 connections to the BOLT simultaneously allowing multiple viewers to see the BOLT’s thermal image in real time. Audio can also be recorded in the app via your smartphone microphone while connected to the app.

Spec Sheet


Objective Lens Material Germanium
Objective Focal Length  35mm
Objective F#  1.1
Optical Magnification 3x
Detection Range 1750 yds
Display Type AMOLED
Display Resolution 1024×768
Focusing Mechanism Manual Focus
Eye Relief 70mm
Digital Magnification  4x, stepped
Diopter Range -4 +4
Vertical Angular Field of View 5.7°
Horizontal Angular Field of View 7.5°
Objective Diameter 35mm
Recoil Rating 1000 g/s²  (300 Win. / 7mm Mag)
Ingress Protection IP67
Operating Temperature Range -4°F – 122°F
Sensor Resolution 384×288
Sensor Pixel Size 12μm
Sensor Frame Rate 12μm
Sensor Type InfiRay MICRO II
Thermal Sensitivity  <50mk
Non-Uniformity Correction (NUC)  Manual, Automatic, Semi Automatic
Spectral Response  8-12 microns
Device Technology  Thermal Imaging
Rangefinder  Bluetooth ILR-1200-1 LRF (Optional)
Onboarding Recording  Yes
Warranty 5 Years
Picture in Picture  Yes
Reticle  6 (1 Dynamic, 5 Static)
Image Capture Yes
Mobile App Yes
Wifi Yes
Video Output Analog RS-170/NTSC
Connector Output  Power / Data
Connector Type USB-C
Color Palettes White Hot, Black Hot, Red Hot, Color, Highlight
User Updatable Firmware Yes
One Shot Zero Yes
Stand By Mode Yes
Storage Capacity 32GB
Power Source Dual Power Supply
Run Time 8+
External Power Source USB-C or 18500 / 18650
Startup Time Under 10 Seconds
Country of Manufacture  China
Length 15.74
Height 2.55
Width 3.34
Mounting Interface  30mm rings (included)
Housing Material  T-6061 Aluminum
Weight 32.87

1 review for InfiRay Outdoor Bolt TL35 V2 Thermal Sight

  1. j_r_a_y (verified owner)

    Only had it a few weeks shot one predator tournament with it so far so good. The battery life is good and the controls are easy to use
