iRay RICO Bravo MK2 Thermal Weapon Sight
The iRay RICO Bravo MK2 is a lightweight thermal optic that was designed for hunters by hunters. The groundbreaking thermal imaging scope features innovative ergonomics, cutting edge connectivity, and iRay’s Matrix III algorithm. It is built around iRay’s Magnetic Omnidirectional Connector that provides a secure connection regardless of angle, with no risk of damage like a traditional USB connector. The next generation Hard Stop Buttons and Tactical Ridge Positioning system allows the user to easily navigate controls without taking their eyes off the target.
The RICO Bravo features manual focus F:1.1 lens, 7 reticle options (2 Dynamic and 5 Static) in Black, White, Red and Green Reticle color options and stadiametric rangefinder. The detection range of the sight is 1750 yards. The housing of the optic is ultra rigid glass filled polymer and features an American Defense RQD quick release mount. The Bravo is designed and assembled in the USA, and backed by a 5 year warranty.
Specifications |
||||||
| Resolution | 384×288 | |||||
| Pixel Size | 12 μm | |||||
| Framerate | 50hz | |||||
| Image Processing | Matrix III | |||||
| Core | iRay Micro II 384 | |||||
| Objective Lens | 35mm F1.1 | |||||
| Magnification | 3x | |||||
| Digital Zoom | 4x, stepped | |||||
| FOV | 7.5° x 5.7° | |||||
| Detection Range | 1750 yards | |||||
| Display Type | High Definition | |||||
| Display Resolution | 1280×960 | |||||
| Imaging Modes | White Hot
Black Hot Red Hot Color Highlight |
|||||
| Reticle Types | 7 (2 Dynamic and 5 Static) | |||||
| Reticle Colors | Black
White Red Green |
|||||
| Mounting System | Picatinny, MIL-STD 1913 / ADM RQD Mount | |||||
| P.I.P. | Yes | |||||
| Rangefinder | Stadiametric | |||||
| Eye Relief | 40mm | |||||
| Diopter Range | -4 to +4 | |||||
| Onboard Recording | Video and Image | |||||
| Wireless Connectivity | Video and Image via App. | |||||
| Data/Power Connector | Magnetic Omnidirectional Connector | |||||
| Power Supply | CR123A x 2 USB via Magnetic Omnidirectional Connector | |||||
| Start Up Time | >10 seconds, instant from standby | |||||
| Size | 7.78”×2.79”×3.13” | |||||
| Weight | 21.2 ounces (with batteries) | |||||
| Warranty | 5 years | |||||
| Housing Material | Ultra Rigid, Glass Filled Polymer | |||||
| Ingress Protection | IP67 | |||||
| Operation Temp | -4°F~122°F | |||||
| Max. Recoil | 1000 g/s2 (300 Win./7mm Mag) | |||||
