Pulsar Axion XM30S Thermal Imaging Monocular


Out of stock

Pulsar Axion XM30S Thermal Imaging Monocular

The Pulsar Axion XM30S is the perfect accessory for exploring the world of darkness. It is designed to fit in one hand or in a standard size pocket making easy to carry on any adventure. Housing is made from light weight magnesium alloy that ensures high structural rigidity and ruggedness while retaining small weight and ergonomics. Thanks to the new revolutionary electronics unit can be started almost instantly. High contrast AMOLED micro display of HD resolution offers crisp image and vivid colours. Display ensures excellent image quality and flawless performance even in freezing temperatures. The 8 color palette enhances viewing in varying conditions.

The Axion XM30s also features a powerful objective lens in combination with a 12 µm professional grade thermal imaging sensor that provides exceptional detection capabilities. A standard 1,8 m (6 ft) tall object can be detected at a 1300 m (1420 yds) distance in complete darkness. Upon activation Picture in Picture function displays second small image with magnification in the top part of the screen. Small image helps to zoom in on a target while retaining the rest of the field of view visible. Axion offers the highest magnification in the class of compact thermal imagers.

It also features a built in video recorder, 16 GB on memory as well as a built in WiFi module that provides connectivity of Axion with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offers a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware update and many other.

Pulsar Axion XM30S Overview

Small and Lightweight Pocket Sized Format

Rugged Magnesium Alloy Housing

Long Detection Range

12 µm Thermal Imaging Sensor

Instant Start Up

8 Color Palettes

High Optic Magnification

IPX7 Waterproof rated up to 3 feet of water for up to 30 minutes.

HD AMOLED Microdisplay

Picture in Picture Function

B-Pack Mini Power System

Video and Still Photo Recording

Stream Vision App Supported

Battery Used

Type: APS 3 (Li-Ion) Battery Pack

Quantity: 1


Sensor 320 x 240 pix. @ 12 µm
Objective Lens F30/1.2
Magnification, x 4.5 – 18 (x4 zoom)
Detection Range, m 1300
Type uncooled
Resolution, pixels 320 x 240
Pixel Pitch, µm 12
Frame Rate, Hz 50
Objective Lens F30/1.2
Magnification, x 4.5 – 18
Field of View (HxV), degrees / m @ 100 m 7.3 x 5.5 / 12.8 x 9.6
Resolution, pixels 1024 x 768
Detection Range, m 1300
Video / Photo Resolution, pixel 1024 x 768
Video / Photo Format .mp4 / .jpg
8 Palette Options White Hot, Hot Black, Red Monochrome, Sepia, Red Hot, Rainbow, Ultramarine and Violet
Built In Memory, Gb 16
Degree of Protection, IP Code (IEC60529) IPХ7
Operating Temperature Range, °С -25 – +40
Dimensions, mm 143 x 41 x 69
Weight, kg 0.25
Output Voltage, V 3.0 – 4.2
Battery Type Li-Ion Battery Pack APS3
Capacity, mAh 3200
Operating Time on Battery Pack (at t=22°C), h * 4+
External Power Supply 5V
Frequency 2.4GHz
Standard 802,11 b/g
Line of Sight Reception Range, m 15
