Description

Sightmark Core TX 8.5-25x50mm Marksman Scope

Sightmark Core TX 8.5-25x50mm Marksman Scope use fully multi coated optics to provide optimal light transmission in a variety of conditions. Etched glass reticles, in red or green, are illuminated to deliver optimal shot placement and are durable to withstand years of shooting. The Core TX scopes feature exposed, lockable turrets which help maintain a consistent zero.

Turrets are quick and easy to adjust to compensate for bullet drop and windage on the fly. The Core TX 8.5-25x50MR Marksman is housed in a durable 30mm tube, built from aircraft grade aluminum and features a side focus adjustment for parallax removal. The Marksman Reticle (MR) is designed for long range shooting. Its MOA scale allows for ranging targets and features holdovers for bullet drop and wind.

Sightmark Core TX 8.5-25x50mm Features

Exposed, lockable turrets

Second focal plane reticle

Red/Green illuminated reticle

Side focus adjustment for parallax removal

Single piece, 30mm tube

Aircraft grade aluminum

Hard anodized finish

Shockproof, fogproof, weatherproof

Fully multi-coated optics

Product Manual

Included in Package

Flip up lens covers

30mm scope rings

CR2032 battery


Specifications

Reticle Type Marksman Reticle (MOA)
Reticle Etched Glass
Reticle Color Red
Green
Reticle Illuminated Yes
Reticle Brightness Setting 0-5
Finish Color Matte black
Magnification 8.5-25
Diameter Eyepiece 1.73in
(44mm)
Diameter Exit Pupil 5.8-2mm
Eye Relief 4-3.7in
(101.6-94mm)
FOV 4.23-1.4m @ 100m
FOV 12.7-4.2ft @ 100yd
Diopter Adjustment +3 -3
Diameter Tube 30mm
(1.18in)
Parallax Setting 10-∞ yds
MOA Adjustment 1/8 one click
Windage Adjustment 50 MOA
Elevation Adjustment 50 MOA
Windage & Elevation Adjustment Range mm yes
Maximum Recoil 1,200G’s
Battery Type CR2032
Battery Life 100-70
hours
Battery Voltage 3V
Sunshade No
Nitrogen Filled yes
Shockproof yes
Fog Proof yes
Focal Plane 2nd
IP Standard IP67
Body Material Aluminum
Material Lens Glass
Lens Coating Fully Multi-coated
Operating Temperature 0 to 120F
(-17 to 49C)
Length 14.1in
(358mm)
Width 3.2in
(81mm)
Height 2.5in
(63mm)
Weight 29oz
