Description

Sightmark Core TX riflescopes use fully multi-coated optics to provide optimal light transmission in a variety of conditions. Etched glass reticles, in red or green, are illuminated to deliver optimal shot placement and are durable to withstand years of shooting. The Core TX riflescopes feature exposed, lockable turrets which help maintain a consistent zero. Turrets are quick and easy to adjust to compensate for bullet drop and windage on the fly. The Core TX 8.5-25x50MR Marksman is housed in a durable 30mm tube, built from aircraft grade aluminum and features a side focus adjustment for parallax removal. The Marksman Reticle (MR) is designed for long range shooting. Its MOA scale allows for ranging targets and features holdovers for bullet drop and wind.


Specifications

Reticle
Type
Marksman
Reticle
(MOA)
Reticle Etched
Glass
Reticle
Color
Red
Green
Reticle
Illuminated
Yes
Reticle
Brightness
Setting
0-5
Finish
Color
matte
black
Magnification 8.5-25
Diameter
Eyepiece
1.73in
44mm
Diameter
Exit
Pupil
5.8-2mm
Eye
Relief
4-3.7in
101.6-94mm
FOV 4.23-1.4m
@ 100m
FOV 12.7-4.2ft
@ 100yd
Diopter
Adjustment
+3
-3
Diameter
Tube
30mm
1.18in
Parallax
Setting
10-∞
yds
MOA
Adjustment
1/8 one
click
Windage
Adjustment
50 MOA
Elevation
Adjustment
50 MOA
Windage &
Elevation
Adjustment
Range
mm
yes
Maximum
Recoil
1,200G’s
Battery
Type
CR2032
Battery
Life
100-70
hours
Battery
Voltage
3V
Sunshade No
Nitrogen
Filled
yes
Shockproof yes
Fog
Proof
yes
Focal
Plane
2nd
IP
Standard
IP67
Body
Material
Aluminum
Material
Lens
Glass
Lens
Coating
Fully
Multi-coated
Operating
Temperature
0 to 120F
-17 to 49C
Length 14.1in
358mm
Width 3.2in
81mm
Height 2.5in
63mm
Weight 29oz

Additional information

Weight 1.8 lbs
