Steiner Nighthunter H35 Thermal Handheld
The Steiner Nighthunter H35 Thermal Handheld was designed to deliver exceptional performance with crisp clear images, even in the darkest part of the night. The heart of the Nighthunter H35 is Quantum Vision, which is a perfect combination of a state of the art thermal sensor, outstanding display quality and proprietary software. Quantum Vision technology, together with outstanding usability, handling and legendary ruggedness, creates the product you have been waiting for.
The Nighthunter line of thermal optics is the evolution of Steiner’s drive to improve low light performance, and expansion of the highest performing, most durable optics on earth. Don’t fear the dark, hunt confidently with the Steiner Nighthunter H35.
Steiner Nighthunter H35 Thermal Handheld Features
The Sharpest Thermal Images
640 x 512 thermal sensor
Best Imagery for Life’s Defining Moments
Fast and smooth automatic calibration
Clear Pictures of Moving Targets
High frame rate
Wherever – Whenever
Steiner high speed software
See While Others Guess
High contrast and outstanding sensitivity
Customizable Output
Various mods and color palettes
Optimal Visibility – in Any Light Condition
High quality LCOS display
Comfortable Observation
1280 x 960 resolution
Exceptional Optic Performance
The Nighthunter H35 delivers on the darkest of nights with crisp, clear images in a reliable thermal optic.
Rugged Durability
Designed to operate in all conditions you might encounter in the field.
Quantum Vision
Perfect combination of the state of the art thermal sensor, outstanding display quality and proprietary software.
Warranty
The Nighthunter H35 thermal is covered by the Steiner 2 year warranty and Steiner will repair or replace your product if it is defective. Do not disassemble the thermal imager as this will void the warranty. Contact your nearest Steiner dealer for assistance.
Specifications |
||||||
Resolution | 640 x 512 @ 12 μm | |||||
Spectrum | 8 ~ 14μm | |||||
NETD | ≤50mk @ F1 25°C | |||||
Focal Length | 35mm F1.0 | |||||
Focus | Manual | |||||
Field of View @ 100m | 12.5 x 9.4 m | |||||
Output Frame Rate | 50Hz | |||||
System Magnification | 2x-16x | |||||
Battery | 2* 18650, 6000 mAh, built in | |||||
Charging Method | Multi changeable plugs GB/AU/EU/CN/UL | |||||
Adaptor | Standard USB power adaptor 5VDC, max, 10W | |||||
Working Time | Battery continuous working time ≥4.5 hours @25°C (only watching) | |||||
USB | Type C (USB 2.0 Standard), rechargeable, support data transmission | |||||
Video Interface | Micro HDMI | |||||
WiFi | Support Wifi (APP) communication, realtime video transmission | |||||
Display | LCOS | |||||
Resolution | 1280 x 960 | |||||
Max Screen Size with 1 Meter Distance | 22 inches | |||||
Magnification | 2.04x | |||||
Video Output Format | Digital Video | |||||
Memory Capacity | 16GB | |||||
Working Temp | 14°F — 122°F | |||||
Storage Temp | –22°F — 140°F | |||||
Humidity | 10% ~ 95%, not-condensing | |||||
Shock | 30G 11ms semi-sinosoidal IEC60068-2-27 | |||||
Vibration | 10Hz ~ 150Hz ~ 10Hz 0.15mm IEC60068-2-6 | |||||
Drop | 1m Drop | |||||
Waterproof | Yes | |||||
Certification | UN38.3, RoHS, CE, FCC, EAC |
Detection |
||||||
Man | 1800m | |||||
Vehicle | 4400m | |||||
Deer | 3200m | |||||
Coyote | 2000m |
Recognition |
||||||
Man | 450m | |||||
Vehicle | 1100m | |||||
Deer | 825m | |||||
Coyote | 500m |
Identification |
||||||
Man | 225m | |||||
Vehicle | 550m | |||||
Deer | 400m | |||||
Coyote | 250m |
