Description

Vortex Crossfire II AO 4 – 16 x 50 mm

The Vortex Crossfire II 4 – 16 x 50 AO is equipped with a long eye relief, fast focus eyepiece, a fully multi coated lenses, and a resettable MOA turret. The scope is constructed of a single piece aircraft grade aluminum with a hard anodized finish. It is nitrogen purged and is o-ring sealed making it both fog proof and waterproof.

Crossfire II AO 4 – 16 x 50 mm Features

Fully Multi-Coated

Second Focal Plane Reticle

30 mm Diameter Tube

Single Piece Tube

Constructed of Aircraft Grade Aluminum

Waterproof, Fog Proof, Shockproof

Hard Anodized Finish

Capped Reset Turrets

Fast Focus Eyepiece




Specifications

L1 14.37
L2 1.9
L3 2.3
L4 5.6
L5 5.16
L6 3.6
H1 2.52
H2 1.73



Specifications

Magnification 4-16x
Objective Lens Diameter 50 mm
Eye Relief 3.7 inches
Field of View 25-3.7 ft/100 yds
Tube Size 30 mm
Turret Style Capped
Adjustment Graduation 1/4 MOA
Travel Per Rotation 15 MOA
Max Elevation Adjustment 50 MOA
Max Windage Adjustment 50 MOA
Parallax Setting 25 yards to infinity
Length 14.37 inches
Weight 23.6 oz




Additional information

Weight 1.5 lbs
Vortex Reticle Option

Dead-Hold BDC, V-Plex
