Description

OPTICAL FEATURES

Fully Multi-Coated Lenses

Anti-reflective lens coatings provide brighter views.




CONSTRUCTION FEATURES

Waterproof

O-ring seals prevent moisture, dust, and debris from getting inside for withstanding harsh weather conditions.

Rugged Design

Built to handle tough situations. Compact and lightweight.

Rubber Armor

Provides a secure, non-slip grip.

Diopter

Adjusts for precise focus.

Utility Clip

Provides quick, convenient access.

Tripod Adaptable

Compatible with a tripod adapter, allowing use on a tripod or car window mount.




PERFORMANCE FEATURES

HCD

Horizontal Component Distance (HCD) mode for angle compensated ranging.

LOS

Line of Sight (LOS) mode displays actual line of sight range.

Scan

This feature displays continual distance readings when panning across a landscape or tracking a moving animal.

Easy-to-use Menu

Intuitive, easy-to-use menus feature a simple, clean illuminated display.

Ranging Format

Range in yards or meters.




Specifications

Range Reflective 9-1300 yards
Range Deer 9-600 yards
Accuracy + / – 3 yards @ 1000 yards
Max Angle Reading +/- 60 degrees (INC 50)
Magnification 6 x
Objective Lens Diameter 22 mm
Linear Field of View 315 feet/1000 yards
Angular Field of View 6 degrees
Eye Relief 17 mm
Operating Temperature 14°-131°F
Length 3.9 inches
Width 3 inches
Weight 7.7 ounces

Additional information

Weight 0.5 lbs
