Warne Winchester 70 WSM Mountain Tech Tactical Rail

The Warne Winchester 70 WSM Mountain Tech Tactical Rail is built with versatility and stability. It offers the user the advantage of a consistent mounting platform across multiple firearms, enhanced ability to adjust proper eye relief and superior alignment of ring mounts. With self centering hardware and aerospace grade materials Warne’s Mountain Tech rails provide a lightweight and robust platform for your rifle.

Warne Mountain Tech is the ultimate lightweight precision scope mounting system. Don’t leave your dream hunt to chance. When every ounce matters, and every shot counts, Warne Mountain Tech are the scope mounts you can depend on.

Warne Winchester 70 WSM Mountain Tech Tactical Rail Features

Precision CNC machined from 7075/T6 aluminum for a high strength & lightweight platform

Mil-Spec hardcoat anodized finish for abrasion and corrosion resistance.

Bases feature black zinc coated hardware for “Element Proof” protection.

Self centering tapered T-15 Torx screws.

Fits Picatinny & Weaver style mounts and are NATO-STANAG compatible.

Fits Model 70 WSM & Short Action with 5.23″ furthest holes center to center


Installation Instructions

Always verify that your firearm is UN-LOADED before performing any service on it. Warne recommends that you loosely assemble rings and scope onto firearm prior to final mounting to verify eye relief and ring spacing.

  1. Visually inspect your firearm’s receiver for burrs around the screw holes and remove if necessary. Remove all oil and grease from the holes in the receiver, the base screws and contact surfaces.
  2. Place the base(s)/rail on the receiver.
  3. In some instances the front base will overhang the receiver, place base overhang towards the rear of the firearm.
  4. Check for proper fit and alignment.
  5. If you have short and long screws, please use the short screws in the front of base/rail, front holes of firearm
  6. Using a T-15 wrench (supplied with WARNE rings) loosely install the supplied Torx 15 screws.
  7. If base(s)/rail fit properly, firmly tighten screws.
  8. WARNE recommends no more than *25 in/lb maximum torque.
  9. WARNE recommends the use of a REMOVABLE thread locking compound on base/rail installations only, for best results.
  10. *Never torque your base screws beyond the firearm manufacturers’ recommended torque rating. Use extreme caution when tightening base screws on an aluminum receiver, torque specifications will be significantly lower and you should always check the firearm manufacturers’ recommended torque rating.

IMPORTANT: NEVER OVER TIGHTEN ANY BASE OR RING SCREW. NEVER ATTACH A SCOPE IF THE OBJECTIVE TOUCHES THE BARREL OR CAUSES INTERFERENCE WITH THE BOLT, SAFETY OR CYCLING OF THE ACTION. ALWAYS FOLLOW THE FIREARM OR SCOPE MANUFACTURERS’ RECOMMENDED TORQUE SPECIFICATIONS. YOU ARE RESPONSIBLE FOR YOUR OWN GUNSMITHING METHODS.

            ⇒ If you are unsure or do not have the proper tools, please contact a gunsmith for assistance, Warne will not be held liable for stripped/damaged receivers or scopes.







More from Warne

Additional information

Weight .5 lbs
Options

0 MOA, 20 MOA
