Vortex Viper HS LR 4-16x50mm

Want to extend your effective shooting range at distances where bullet drop and wind drift become critical? Take a look at the Viper HSLR riflescope. The LR stands for long range, and we mean it. This riflescope features an exposed target style elevation turret built for dialing elevation at extended ranges. The capped windage turret maintains the scope’s sleek lines and prevent it from hanging up on clothing, rifle cases or pack scabbards.

The Viper HSLR riflescopes feature an advanced optical system highlighted with a 4x zoom range for magnification versatility. A forgiving eye box with increased eye relief gets shooters on target quickly and easily. Built on an ultra strong 30 mm one piece machined aluminum tube for increased windage and elevation travel and optimal adjustment.

Viper HS LR 4-16x50mm Features

XD Lens Elements

Extra low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images.

XR Fully Multi Coated

Proprietary coatings increase light transmission with multiple anti reflective coatings on all air to glass surfaces.

Second Focal Plane Reticle

Scale of reticle maintains the same ideally sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.

Tube Size

30 mm diameter provides maximized internal adjustment and strength.

Single Piece Tube

Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproof.

Aircraft Grade Aluminum

Constructed from a solid block of aircraft grade aluminum for strength and rigidity.

Waterproof

Fog Proof

Shockproof

Hard Anodized Finish

Highly durable hard coat anodization provides a low glare matte surface and helps camouflage the shooter’s position.

ArmorTek

Ultra hard, scratch resistant coating protects exterior lenses from scratches, oil and dirt.

Tactical Elevation Turret

Exposed elevation turret provides fast, accurate and easily read elevation adjustments. Capped windage turret.

Side Focus

Adjustment located on left side of turret housing is easily accessible from shooting position. Provides optimal image focus and parallax removal.

CRS Zero Stop

Customizable Rotational Stop (CRS) aids in return to zero after dialing temporary elevation correction.

Precision Force Spring System

Uses premium components in the erector spring system to ensure maximum repeatability and ease of adjustment.

Precision Glide Erector System

This system ensures the components in the zoom lens mechanism glide smoothly and cleanly through all magnification ranges.

MAG View Fiber Optic

Provides a highly visible reference point for the magnification setting.

Radius Bar

Fiber optic turret rotation indicator provides a highly visible and tactile point of reference for turret rotations.

Fast Focus Eyepiece

Allows quick and easy reticle focusing.


Specifications

Magnification 4-16x
Objective Lens Diameter 50 mm
Eye Relief 4.0 inches
Field of View 27.4-7.4 ft/100 yds
Tube Size 30 mm
Elevation Turret Style Tactical
Windage Turret Style Capped
Elevation Adjustment Graduation 1/2 MOA
Windage Adjustment Graduation 1/4 MOA
Elevation Travel Per Rotation 24 MOA
Windage Travel Per Rotation 12 MOA
Max Elevation Adjustment 75 MOA
Max Windage Adjustment 50 MOA
Parallax Setting 50 yards to infinity
Length 13.56 inches
Weight 21.4 oz
