Description

Sightmark Core TX DCR 1-4x24mm Tactical Scope

Sightmark Core TX DCR 1-4x24mm Tactical Scope use fully multi coated optics to provide optimal light transmission in a variety of conditions. Etched glass reticles, in red or green, are illuminated to deliver optimal shot placement and are durable to withstand years of shooting.

The Core TX scopes feature exposed, lockable turrets which help maintain a consistent zero. Turrets are quick and easy to adjust to compensate for bullet drop and windage on the fly. The Core TX 1-4x24DCR is housed in a durable 30mm tube, built from aircraft grade aluminum. This scope features a duplex BDC reticle and is calibrated for .223 and .308 ammo.

Sightmark Core TX DCR Features

BDC reticle calibrated for .223 and .308 ammo

Exposed, lockable turrets

Second focal plane reticle

Red/Green illuminated reticle

Single piece, 30mm tube

Aircraft grade aluminum

Hard anodized finish

Shockproof, fogproof, waterproof

Fully multi-coated optics

Product Manual

Included in Package

Flip up lens covers

30mm scope rings

CR2032 battery


Specifications

Reticle Type DCR Dual Caliber Reticle
Reticle Etched Glass
Reticle Color Red
Green
Reticle Illuminated Yes
Reticle Brightness Setting 0-5
Finish Color Matte Black
Magnification 1-4x
Diameter Objective Lens 24mm
Diameter Eyepiece 1.65in
(42mm)
Diameter Exit Pupil 11-6mm
Eye Relief 4-3.7in
(101.6-94mm)
FOV 32.04-8.03m @ 100m
FOV 96.1-24.1ft @ 100yd
Diopter Adjustment +2 to -2
Diameter Tube 30mm
(1.18in)
Parallax Setting 100 yds
MOA Adjustment 1/2 MOA
Windage Adjustment 80 MOA
Elevation Adjustment 80 MOA
Windage Adjustment Yes
Maximum Recoil 1,200G’s
Battery Type CR2032
Battery Life 100-70 Hours
Battery Voltage 3V
Sunshade No
Nitrogen Filled Yes
Shockproof Yes
Focal Plane 2nd
Fog Proof Yes
IP Standard IP67
Body Material Aluminum
Lens Coating Fully Multi-coated
Material Lens Glass
Operating Temperature 0 to 120F
(-17 to 49C)
Length 9.64in
(245mm)
Width 3.2in
(81mm)
Height 2.5in
(63mm)
Weight 17oz












More Rifle Scopes

Additional information

Weight 1.1 lbs
