AGM Taipan V2 19-320 Thermal Imaging Monocular
The AGM Taipan V2 19-320 Thermal Monocular is the newest addition to what is already the most extensive thermal product assortment in the world! The Taipan V2 series boasts multiple objective lens sizes which are paired with an industry-leading 12 micron thermal detectors. It also bring many new advancements to the product family which users have been clamoring for in the original Taipan monoculars. These primary improvements include moving from a non-removable rechargeable internal battery to a single removable rechargeable 18650, a new 320×256 thermal sensor and a new 90 degree tilt sensor which powers off the display to save battery life!
The Taipan V2 19-320 also comes packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: F1.0 aperture optics, 50Hz refresh rate, 16GB of built-in memory, Wi-Fi compatibility to pair with the AGM Connect App, an IP67 waterproof rating, USB Type-C port for external power capabilities and 4 color palettes. They also utilize a wider rubber eyepiece to make viewing the 1280 LCOS display extremely comfortable in the field when viewing for long periods of time in a single session.
AGM Taipan V2 19-320 Features
Upgraded sub-35mK 12 micron thermal detector
320×256 resolution
50 Hz image frame rate
Advanced image processing
1280×960 resolution LCOS display
Built-in recording with sound
16 GB memory module
Wi-Fi hotspot
Magnification – 3× – 22.5x
Auto screen off with tilt sensor
Replaceable and rechargeable Li-Ion battery
Up to 6 hours of battery life
External power supply capability
Rugged housing with rubber overmolding
Waterproof
Compatible with AGM Connect App
5-year warranty
Specifications |
||||||
| Palettes | Black Hot, White Hot, Red Hot, Fusion | |||||
| Dimensions | 173 × 60 × 64 mm
(6.8 × 2.4 × 2.5 in) |
|||||
| Exit Pupil Diameter | 6 mm | |||||
| Distance Measurement | Yes | |||||
| Scene Mode | General, Compressed | |||||
| Picture In Picture Mode (PIP) | Yes | |||||
| Hotspot | Yes | |||||
| Video Recording | Yes | |||||
| Audio Recording | Yes | |||||
| Magnification | 3×, 6x, 11x, 22.5x | |||||
| Detector type | 12μm VOx Uncooled Focal Plane Array | |||||
| Response Waveband | 8μm to 14μm | |||||
| FFC (Flat Field Correction) | Auto, Semi-Auto, Manual | |||||
| Standby Mode | Yes | |||||
| Refresh rate | 50 Hz | |||||
| Resolution | 320×256 | |||||
| Detection Range (6′ object) | 950 m | |||||
| Snapshot | Yes | |||||
| Lens system | 19 mm; F1.0 | |||||
| NETD | Less than 35 mK (25°C, F#=1.0) | |||||
| Field of view (H × X) | 9.2° × 6.9°/16.2 m x 12.1 m | |||||
| Diopter adjustment range | -4 D to +4 D | |||||
| Monitor | 1280×960, 0.4 inch, LCOS | |||||
| Focusing range | 1.9 m minimal | |||||
| Hot Track | Yes | |||||
| Eye relief | 20 mm | |||||
| Storage | Built-in EMMC (16 GB) | |||||
| Battery Type | One 18650 Replaceable rechargeable Lithium battery | |||||
| Battery Life (Operating) | Up to 6 hours continuous running (@25°C, WiFi off) | |||||
| Power supply | 5 VDC/2 A, USB Type-C interface. Supports external power supply | |||||
| Operating Temperature Range | -30°C to +55°C
(-22°F to 131°F) |
|||||
| Weight | 0.3 kg
(0.66 lb) |
|||||
| Protection Level | IP67 (Waterproof) | |||||
