Description

MGR Reticle

Designed by U.S. Optics, this MIL based reticle offers full MIL, .5 MIL and .2 MIL hash marks. The open center features a broken cross to provide a clear view of the shooter’s groupings, while the fine crosshairs present a clear and crisp image without obscuring the target. The MGR provides 6 MILs of wind and 11 MILs of elevation holdovers.


Elevation Knob: 1/10 MIL EREK 2


Elevation Travel*: 22 MILS


Windage Knob: US#5, 1/10 MIL


Windage Adjustment Range*: 10L / 10R


Reticle: MIL Scale GAP, First Focal Plane


*30 MOA Down


Specifications

Magnification 5-25x
Exit Pupil Diameter 2 mm
Diopter +2 to -3
Parallax Adjustment 75yds to ∞
Field of View @ 5x 16.08’ @ 100 yards
Field of View @ 25x 5.25’ @ 100 yards
Eye Relief 3.2” /8.12 cm
Objective Lens Housing Diameter 2.38” / 60.48mm
Tube Diameter 1.33” / 34mm
Overall Length 17.93” /455.42mm
Objective Lens Diameter 2.04” / 52mm
Ocular Lens Diameter 1.40” / 35mm
Weight 34.9oz /0.99kg
Reticle Illumination Red
Battery Lithium Coin, CR2032
Battery Runtime Up to 500 Hours
Material Aluminum, 6061-T6
Finish Color Matte Black

Additional information

Weight 3.44 lbs
