Vortex Viper HS LR 6-24x50mm
The Vortex Viper HS LR riflescopes feature an advanced optical system highlighted with a 4x zoom range for magnification versatility. A forgiving eye box with increased eye relief gets shooters on target quickly and easily. Built on an ultra strong 30 mm one piece machined aluminum tube for increased windage and elevation travel and optimal adjustment.
Viper HS LR 6-24x50mm Features
XD Lens Elements
Extra low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images.
XR Fully Multi Coated
Proprietary coatings increase light transmission with multiple anti reflective coatings on all air to glass surfaces.
First Focal Plane Reticle
Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications.
30 mm diameter provides maximized internal adjustment and strength.
Single Piece Tube
Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
Aircraft Grade Aluminum
Constructed from a solid block of aircraft grade aluminum for strength and rigidity.
Hard Anodized Finish
Highly durable hard coat anodization provides a low glare matte surface and helps camouflage the shooter’s position.
Ultra hard, scratch resistant coating protects exterior lenses from scratches, oil and dirt.
Tactical Elevation Turret
Exposed elevation turret provides fast, accurate and easily read elevation adjustments. Capped windage turret.
Adjustment located on left side of turret housing is easily accessible from shooting position. Provides optimal image focus and parallax removal.
CRS Zero Stop
Customizable Rotational Stop (CRS) aids in return to zero after dialing temporary elevation correction.
Precision Force Spring System
Uses premium components in the erector spring system to ensure maximum repeatability and ease of adjustment.
Precision Glide Erector System
This system ensures the components in the zoom lens mechanism glide smoothly and cleanly through all magnification ranges.
MAG View Fiber Optic
Provides a highly visible reference point for the magnification setting.
Fiber optic turret rotation indicator provides a highly visible and tactile point of reference for turret rotations.
Fast Focus Eyepiece
Allows quick and easy reticle focusing.
XLR RETICLE (MOA)
Hash marked MOA based long range reticle with wind drift dots and 1 MOA wind reference subtensions. Good for long range shooters dialing for bullet drop or holding drop while using the reticle.
|Objective Lens Diameter||50 mm|
|Eye Relief||4.0 inches|
|Field of View||17.8-5.1 ft/100 yds|
|Tube Size||30 mm|
|Elevation Turret Style||Tactical|
|Windage Turret Style||Capped|
|Elevation Adjustment Graduation||1/2 MOA|
|Windage Adjustment Graduation||1/4 MOA|
|Elevation Travel Per Rotation||24 MOA|
|Windage Travel Per Rotation||12 MOA|
|Max Elevation Adjustment||65 MOA|
|Max Windage Adjustment||42 MOA|
|Parallax Setting||50 yards to infinity|
