BoBro Trijicon ACOG Mount

$165.00

Backorder this item now

Fast & Free Shipping $199+

SKU: B05-000-001 Categories: , , Tag: Brand:

Description

BoBro Trijicon ACOG Mount

The BoBro Trijicon ACOG Mount was designed with the BLAC lever system and the mounting channel and height of mount is to Trijicon’s factory dimensions. Trijicon supplied critical dimensions, so the mount is completely within the manufacturers specifications, and will work with the ACOG properly. It is constructed of Aluminum Alloy 6061-T6 and hard anodized to Mil-Spec. The mount is 3.5 inches long with 2 mounting fastener allocations.

It can be configured for left/right lever placement. It utilizes a single BOBRO mechanical index and uses the factory supplied fastener for attachment to the mount body. The mount features the patent pending BLAC lever system which requires no manual adjustment to attain a proper, rock solid engagement on a 1913 Picatinny rail.

Specifications

Material 6061-T6 Aluminum
Finish Type 3 Hard Coat Black Anodizing
Weight 3.4 oz

Features

BoBro Trijicon ACOG Mount Design Features

  • The ACOG mount features the Patented [US Patent 8,567,105] BLAC lever system which was designed around the following parameters:
  • Must be compatible with any 1913 Specification Rail, to include systems that are out of specification (within reason) and this includes Weaver rails.
  • Must be completely tool and user adjustable free. It needs to be 100% self contained and mate securely to any rail without the user having to tailor the pressure/engagement position.
  • Must lock with enough pressure to positively attach any device or optical instrument to a rail without movement, static or dynamic forces not withstanding.
  • The rail must not experience any deformation due to user error. This must include synthetic (plastic/polymer/composite) rail systems.
  • Auto Index capability. The device must also index parallel to the bore. The unit must always repeat the forward shift (recoil forces direction of influence) not only to maximize zero repeatability, but to take this step of installation out of the users initial mounting sequence. Index must be redundant.
  • Unit must not shoot loose due to improper mounting or a mechanical bottoming out.
  • The system must incorprate a safety that prevents the lever from being accidentally opened. The safety must be able to be manipulated in conjunction with the lever rotation, so that only one hand is required to open it.
  • The unit will utilize constant force to ensure required pressure in all conditions. The force must be substantial to prevent any shift forward/aft left/right.
  • The pressure must be applied in a linear direction centered in the main body to prevent cocking of the mount.
  • It must be easy to manipulate by gloved or fatigued hands.
  • It must be extremely robust, and withstand shock and impact to the system housing.
  • There were others, but by listing them we would compromise our trade secrets.
  • Materials & Construction
  • The ACOG mount is precision CNC machined from a block of 6061 T6 aluminum and finished in hard coat type 3 mil-spec anodized black for a rock hard lasting finish.
  • Reviews

    There are no reviews yet.

    Be the first to review “BoBro Trijicon ACOG Mount”
