| Delivery Scope |
Contoured neoprene carrying strap, front lens cover, eyepiece caps, cordura case, battery |
| Magnification |
10 x |
| Front Lens Diameter |
32 mm |
| Exit Pupil |
3.2 mm |
| Twilight Factor |
16 |
| Field of View at 1.000yds / 1000m |
345 ft. / 115 m |
| Field of View for Spectacle Wearers |
> 334 ft. / > 112 m |
| Eye Relief |
16 mm |
| Objective Angle of View |
5.8° |
| Close Distance |
approx. 16 ft. / 5 m |
| Light Transmission |
91% |
| Diopter Compensation |
±4 dpt. |
| Range |
10 up to approx. 2,500 yds / 2.300m |
| Equivalent Horizontal Range (EHR) |
10 up to approx. 1,200 yds / 1,100m |
| Measuring Accuracy |
±0,5 m at 10-200 m / 0,5 yds at 10-219 yds±1,0 m at 200-400 m / 1,0 yds at 219-438 yds±0,5 % above 400 m / 0,5 % above 438 yds |
| Measuring Time |
Max. approx. 0.3 sec. |
| Measuring Modes |
Scanning mode, single measurement |
| Switchover Meter/Yards |
Yes |
| Ballistic Function |
Yes |
| On Board Wind Correction |
Yes |
| Output “Equivalent Horizontal Range” |
Yes |
| Output “Elevation and Windage correction” |
Yes |
| Output “Click Correction” for Elevation and Windage |
Yes |
| Pre Installed Ballistic Curves |
12 |
| Applied Ballistics Ultralight On Board |
Yes |
| Bluetooth Interface |
Yes |
| Connect to Leica Ballistics App |
Yes |
| Use Customized Ballistic Profiles |
Yes |
| Upgradeable to Applied Ballistics Elite |
Yes |
| Basemaps |
Yes |
| Kestrel / Garmin Connection (AB External Mode) |
Yes |
| GPS Guide |
Yes |
| Display |
LED display with 4 digits, easily legible in any light |
| Eyepiece for Eyeglass Wearers |
Yes |
| Eyecups |
Yes, rotary sliding sleeve, detachable, with 4 click-stops |
| Prism System |
Perger Porro system |
| Lens Coating |
HDC multilayer coating, AquaDura coating |
| Focussing |
Internal focusing via central drive |
| Laser |
4:02:02 |
| Laser Beam Divergence |
1.2 x 0.5 mrad |
| Baromatric Pressure Sensor |
Yes |
| Temperature Sensor |
Yes |
| Temperature Measurement |
Yes |
| Angle Sensor |
Yes |
| Compass |
Yes |
| First Destination Logics |
No |
| Battery |
1 x 3 V / Lithium-type CR2 |
| Battery Lifetime |
Approx. 2.000 measurements at 20°C/68°F |
| Watertighness |
To a depth of 16ft / 5m |
| Housing |
Magnesium, nitrogen filled |
| Dimensions (W x H x D) |
5.1 x 6.0 x 2.8 inch(130 x 153 x 70 mm) |
| Weight |
approx. 30.7 oz(870 g) |
