Description

Leica Pinmaster II Laser Rangefinder

The Leica Pinmaster II Laser Rangefinder allows the user to always know the distance of the golf course up to 750 meters or 2460 feet. It can be used in all weather conditions.

The Pinmaster II Pro has Angle Compensated distance technologies. When calculating the corrected distance, the Leica Pinmaster II takes not only the slope of the terrain into account, but also the distance dependent trajectory of the golf ball with a standard golf ballistic.

Leica Pinmaster II Laser Rangefinder Features

Laser rangefinder

Range of up to 750 m or 2460 ft.

Precise measurement with the First Target Logic

Meter or yard switch

Carbon fiber reinforced and watertight body

LED display adapts automatically to the ambient light and thus weather conditions

ACDTM – Angle Compensated distance Technologies (Pro Version)


Specifications

Laser Type Class 1 Eye Safe
Metering Range 10 to 825 yd (10 to 750 m)
Accuracy < 400 yd / 366 m: ±1 yd / 0.9 m

400 to 825 yd / 366 to 750 m: ±2 yd / 2 m

Beam Divergence 2.5 MRAD
Prism Type Roof
Magnification 7.0 x
Objective Lens Diameter 24 mm
Angle of View 6.5°
Field of View 347′ @ 1000 yd (115 m @ 1000 m)
Exit Pupil Diameter 3.4 mm
Eye Relief 15 mm
Dioptric Correction ±3.5
Form Factor Monocular
Power Source 1 x CR2 Lithium
Inclinometer Yes
Tripod Mount No
Water Resistance Waterproof
Dimensions 4.5 x 3 x 1.3″ (11.3 x 7.5 x 3.4 cm)
Weight 7.8 oz (221.1 g) with battery

Additional information

Weight N/A
Options

Pro, Standard
