Description

Leupold RX-Fulldraw 4 Rangefinder

The Leupold RX-Fulldraw 4 Rangefinder was designed with bowhunters in mind. It gives the user the advantage you need to tag out with their bow. With 1/2 yard, angle compensated accuracy, there’s no second guessing the distance. The RX-FullDraw 4 rangefinder features Leupold’s unique Archer’s Advantage software, which uses arrow weight, arrow velocity, and peep height to calculate extremely accurate ballistic solutions out to 175 yards.

It is Leupold’s first ever Flightpath ranging device that takes the guesswork out of achieving the perfect shot, every time. This extremely fast rangefinder ranges out to 1,200 yards, so even if you’re too far to take the shot, you’ll know how much distance you need to close in order to seal the deal.

Leupold RX-Fulldraw 4 Rangefinder Features

Rangefinder – TBR-Archery

Archer’s Advantage bow ballistics uses your arrow weight, arrow velocity, and peep height to calculate more accurate ranges for steep angle and long distance shots.

OLED

OLED displays use bright red characters and have adjustable brightness setting. This display technology also enables best in class light transmission for use in low light conditions”.

Flight Path

Flightpath™ technology uses your bow’s ballistics to display the highest point of your arrow’s flight, so you can take tighter shots with more confidence.

Line of Sight (LOS)

Line of Sight (LOS) calculates the distance to a target in a straight line, regardless of any incline or decline.

Selectable Reticles

Offers a variety of reticles to choose from to fit any use or preference

Quick Reference Guide

User Manual


Specifications

Finish Green/Black
Magnification 6
Tripod Compatible (1/4-20) No
Rifle Angle Compensation TBR
Archery Angle Compensation TBR – Archery
True Ballistic Range – Wind (TBR-W) No
True Ballistic Range (TBR) No
Horizontal Distance (TRIG-H) Yes
Bow Mode No
True Golf Range (TGR) No
Trophy Scale No
Last Target Mode No
Prism Lock No
Battery Type CR2
Display Color OLED (Red Display)
Length (in) 3.8
Width (in) 1.4
Height (in) 3
Weight (oz) 7.5
Objective Diameter (mm) 22
Linear FOV (ft@1000 yd) 315
Angular FOV (Degrees) 6
Eye Relief (mm) 17
Min Diopter (dpt) -3
Max Diopter (dpt) 3
Light Transmission (%) 85
Battery Life (Actuations) >3000
Accuracy to 125 (yd) .5
Accuracy to 1000 (yd) 2
Accuracy above 1000 (yd) % .5
Max Range – Deer (yd) 900
Max Range – Trees (yd) 1100
Max Range – Reflective (yd) 1200
Max Range – Golf Flag (yd) 0
Min Range (yd) 6
Laser Classification IEC 3R











More from Leupold

Additional information

Weight .25 lbs
