  • Nocpix ACE L35 Thermal Weapon Sight

Nocpix ACE L35 Thermal Weapon Sight

Original price was: $2,799.00.Current price is: $2,499.00.

Backorder this item now

Fast & Free Shipping $199+

SKU: ACE-L35 Categories: , , Tags: , , , , , , , , , , , , , , , , Brand:

Description

Nocpix ACE L35 Thermal Weapon Sight

The Nocpix ACE L35 Thermal Weapon Sight is built around the idea of combining leading user requested features in a streamlined optic that balances advanced capability with ease of use in the field. Designed to feel like a traditional day optic, the Nocpix ACE L35 is compatible with bolt action or semi automatic rifles using standard 30mm mounts and rings. The combination of an internal USB-C charging battery and a removable 18650 style rechargeable battery allows users to hot swap batteries in the field to run indefinitely.

A 1-3x ocular magnification provides optical magnification of the 2560×2560 round AMOLED display inside the eyepiece. The Vision+ system pairs this high resolution display with a 18mK NETD sensor for an incredibly detailed and precise image.

The Nocpix ACE L35 offers a more affordable option in the ACE lineup for predator and hog hunters who don’t require a laser rangefinder or higher resolution sensor. Packing tremendous value, the ACE L35 retains all other features of ACE line of thermal riflescopes.

Spec Sheet

Product Manual

Specifications

Nocpix ACE L35 Spec List

Display Type AMOLED
Eye Relief 50mm
Objective Focal Length 35mm
Digital Magnification 4X
Diopter Range -5 to +5
Vertical Angular Field of View 5.7°
Horizontal Angular Field of View 7.5°
Focusing Mechanism Manual Focus
Objective F# 0.9
Objective Diameter 35mm
Objective Lens Material Germanium
Display Resolution 2560×2560
Detection Range 1970 Yards
Optical Magnification 3X
Operating Temperature Range -4°F~122°F
Recoil Rating 1000 g/s² (300 Win./7mm Mag)
Ingress Protection IP67
Sensor Type Nocpix 384
Sensor Pixel Size 12μm
Thermal Sensitivity <18mk
Non-Uniformity Correction (NUC) Manual, Automatic, Semi-Automatic
Sensor Frame Rate 60hz
Device Technology Thermal Imaging
Sensor Resolution 384×288
Warranty 5 Years
Startup Time <10 Seconds, Instant from Standby
Color Palettes White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian
Picture-in-Picture Yes
Storage Capacity 64GB
Connector Output Power/Data
User-Updatable Firmware Yes
Mobile App Yes
Run Time 7+
Power Source USB-C External, 18650 Battery, Built-In Battery Pack
One-Shot Zero Yes
Stand-by Mode Yes
Connector Type USB-C
External Power Source USB-C
Country of Manufacture China
Wifi Yes
Onboard Recording Yes
Image Capture Yes
Video Output Yes
Mounting Interface QD Picatinny
Housing Material Aluminum Alloy
Weight 37.0 oz.
Height 2.44
Width 3.54
Length 13.78

Features

Nocpix ACE Features

Lens integrated laser rangefinder adds rangefinding capability to the optic and better laser alignment without adding bulk

A 1-3x optical ocular magnifier provides additional magnification of the display without any reticle shift or digital zoom

High contrast round 2560×2560 AMOLED display provides increased clarity and detail

Simplified controls offer improved ergonomics and a better user experience in the field

Uses common 18650 style rechargeable batteries

A ballistic calculator function displays bullet drop values based on the laser rangefinder input data and a user customized cartridge profile

Charge through the unit with a unique lock out USB-C port design
