| Operating Principle |
Reflex Collimator sight with LED |
| Optical Magnification |
1x |
| Aiming Dot Size |
2 MOA, 65 MOA circle & 2 MOA dot |
| Optical Signature |
No optical signature is visible at 10 meter distance, front side, on appropriate settings with NVD |
| Dot Color |
Peak Wavelength: 655 ± 15 nm |
| NVD Compatible |
Yes |
| Optical Coating |
Anti-reflex, all surfaces and multi layer. NVD Compatible. |
| Clear Aperture |
18 mm(.71 in) |
| Eye Relief |
Unlimited |
| Battery Type |
3V lithium battery, type CR2032 |
| Battery Life |
Day time use: 3 years (30,000 h) of continuous use at pos. 7. |
| Power Intensity |
4 NVD and 6 Daylight |
| Size L x W x H (in) Sight Only |
2.7 x 1.5 x 1.7 in(68 x 37 x 43 mm) |
| Size L x W x H (in) Conf |
3.1 x 1.5 x 2.6 in(80 x 37 x 67 mm) |
| Weight (Sight Only) |
108 g(3.8 oz) |
| Weight (Conf) |
160 g(5.6 oz)(lens covers, mount, & battery) |
| Housing Material |
High Strength EN AW 6082 Aluminum |
| Housing Anodized |
Yes |
| Material Mount & Spacer (Standard Conf) |
High strength aluminum |
| Material Lens Cover |
Thermoplastic Elastomer (TPE) |
| Height of Optical Axis |
Sight and mount – 39 mm (1.2 in) measured from top surface of Picatinny/Weaver rail |
| Adjustment |
Range ±1 m at 100 meters (±1 yds at 100 yds) in windage and elevation, 1 click = 15 mm at 100 meters = .5 in at 100 yds |
| Submersible |
25 m(80 ft) |
| Temperature Range Operation |
-45°C to +71°C(-49°F to +160°F) |
| Temperature Range Storage |
-51°C to +71°C(-60°F to +160°F) |
| Temperature Shock |
Operable after a temperature shock between -45°C and +71°C (-49°F and +160°F) |
| Humidity |
Operable during and after humidity. |
| Limits |
RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic |
| Shock |
Withstands shock. Limits: X axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction. |
| Vibration |
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. |
| Frequency |
10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, |
| Time |
30 min/direction. |
| Chemical Resistance |
Withstands occasional contamination by weapons cleaners, lubricants, fuels and insect repellents. |
| Keyed Surface Mount |
One Piece Torsion Nut 39 mm Mount |
