| Operating Principle |
Reflex collimator sight with LED |
| Optical Magnification |
1x |
| Aiming Dot Size |
2 MOA |
| Dot Intensity |
Visible against a background luminance of 0.1 to 55000 1x |
| Dot Color |
Peak Wavelength 655 ± 15nm |
| NVD Compatible |
No |
| Optical Coating |
Anti reflex, all surfaces and multi layer |
| Clear aperture |
29 mm (1.14 in) |
| Eye Relief |
Unlimited |
| Battery Type |
3v lithium battery, type CR2032 |
| Battery Life – Day Time Use |
50,000 h (over 5 years of continuous use) |
| Power Intensity |
1 off position and 12 daylight settings |
| Length Sight Only |
197mm (7.8 in) |
| Width Sight Only |
47mm (1.9 in) |
| Height Sight Only |
47mm (1.9 in) |
| Weight Sight Only (Including Battery) |
253 g (8.9 oz) |
| Housing Material |
High Strength Aluminum |
| Housing Finish and Color |
Semi Matte Black |
| Housing Anodized |
Yes |
| Material Mount and Spacer STD Conf |
High strength aluminum |
| Material Lens Cover |
Thermoplastic Elastomer (TPE) |
| Surface Treatment |
Anodized, Semi Matte |
| Adjustment |
1 click = 20 mm at 100 meters = .6 in at 80 yds |
| Temperature Range Operation |
-30°C to +60°C (-20°F to +140°F) |
| Temperature Range Storage |
-51°C to +71°C (-60°F to +160°F) |
| Temperature Shock |
Operable after a temperature shock between -30°C and +60°C (-22°F and +140°F) |
| Humidity |
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic |
| Submersible |
To a depth of 1 m (3 ft.) |
| Shock |
Withstands shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction) |
| Vibration |
Withstands vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction |
| Chemical Resistance |
Withstands occasional contamination by weapons cleaners, lubricants, fuels and insect repellents. |
| Keyed Surface Mount |
25 |
| Mounting |
2 Rings (not included) |
| Max Distance Between Rings mm/” |
108mm (4.3 in) |
