Description

Aimpoint Hunter H30L Red Dot Sight

The Aimpoint Hunter H30L Red Dot Sight was designed to offer premium quality and reliability for users with a traditional bolt action in large calibers. It provides the ultimate accuracy with a precise 2 MOA red dot and forward mounted adjustment system to ensure faster target acquisition. It can be mounted using any standard 30mm rings. The Hunter H30L has an extremely rugged and durable construction and digital push button intensity settings that ensure it is ready for any weather and light conditions. It is ideal for use on rifles with standard or magnum actions, and it suits any hunter who desires the classic lines of a full length sight. Now with transparent rear and front flip up covers included.

Aimpoint Hunter H30L Red Dot Sight Features

2 MOA dot size

50,000 hours (over 5 years) of constant operation on one battery

12 position digital push button intensity adjustment

Weight 238 g (8.4 oz) sight only

Submersible to 1 meter (3 feet)

Ideal for use on rifles with standard or magnum actions

Multi coated 35 mm objective lens

2 ring configuration fits nearly all 30 mm ring mounting systems

Silent digital push button intensity adjustment for ease of use in the field while wearing gloves

Anodized high strength aluminum housing, semi matte black

Legendary Aimpoint ruggedness

Includes: Flip-up Lens Covers, CR2032 Battery, Aimpoint Tool

Use: Hunting, Sports Shooting and Home Defense

User Manual

Hunter Series Zeroing Target

Product Sheet


Specifications

Size L x W x H 240 x 56 x 56 mm

(9.4 x 2.2 x 2.2 in)

Weight 247 g

(8.7 oz)

Dot Size 2 MOA
Magnification 1X – No Magnification
Night Vision Device (NVD) Compatible No
Transmission Average 60% in the range 420 – 700 nm
Eye Relief Unlimited
Mounting Solution Not Included
Operating Principle Reflex collimator sight – red dot sight
Diode LED (Light Emitting Diode) totally eye safe
Dot Color Red
Dot Intensity Visible against a background luminance of 0.1 to 55 000 lx
Light Source Wavelength 650 nm red light
Optical Coating Anti-reflex coating all surfaces and multilayer coating objective lens
Clear Aperature 25 mm / 1.0 in
Parallax Parallax free – No centering required
Battery Life 50,000 h at daylight setting 7 (room temperature)
Battery Type CR2032, 3V, Lithium
Power Switch Push Buttons
Daylight (DL) Settings 12
Material Housing and Tube High Strength Aluminum
Surface Finish Housing Anodized, Semi-Matte
Color Housing Black
Tube Diameter 30 mm

(1.2 in)

Lens Covers Flip-up Lens Covers, Transparent
Material Lens Covers Thermoplastic Elastomer (TPE)
Adjustment 1 Click = 20 mm at 100 m

(0.7 in at 100 yds)

Submersible 1 m

(3 ft)

Laser No Laser Emission
Radioactive Material None
Temperature Range Operation – 30°C to + 60°C

(- 20°F to + 140°F)

Temperature Range Storage – Operable after a temperature shock between – 51°C to + 71°C

(- 60°F to + 160°F)

Temperature Shock Operable after a temperature shock between – 30°C and + 60°C

(- 22°F and + 140°F)

Humidity – Operable during and after Humidity. Limits Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Shock – Operable before and after shock. Limits Operable before and after shock. Limits X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
Vibration – Withstands vibration. Limits Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency:10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Chemical Resistance Withstands occasional contamination by weapons cleaners, lubricants, fuels and insect repellents.
Mounting Solution Not Included
Max Ring Width 40 mm

(1.6 in)

Max Distance Between Rings 108 mm

(4.3 in)
