Description
Leica Rangemaster CRF 2800.COM
The Leica Rangemaster CRF 2800.COM is the first dedicated compact laser rangefinder that has the capabilities to do precise measurements up to 2,800 yards or 2,600 meters. It has a user friendly Leica Hunting App. The ABC Ballistics can be customized through a smartphone or with a Kestrel Elite weather meter.
The rangefinder gives users three ballistic outputs in addition to the measured distance. It can provide hold over values in inches, centimeters, or come ups in MOA or MILs to 1,000 yards or Equivalent Horizontal Range (EHR) to 1,200 yards. The CRF 2800.COM will display elevation and windage corrections while connected to a Kestrel 5700 Elite with Applied Ballistics.
Data is shown on the integrated LED display, which automatically adjusts to ambient lighting conditions. The scan mode measures environmental conditions and target distance every 0.3 seconds. Between 10 and 200 yards, the CRF2800.COM displays distance to the tenth of a yard, an especially useful feature for archers. Thanks to its compact size and weight, it can easily be carried in a shirt pocket.
Leica Rangemaster CRF 2800.COM Features
Leica’s first compact Bluetooth rangefinder
Easy to use with the Leica Hunting App, available on the Apple App Store and Google PlayStore
Choose between the three output values: clicks, EHR and holdover
Real distance up to 2600 meters
Below 180 meters precise information in decimal values
Specifications |
||||||
| Objective angle of view | 6.6° | |||||
| Coating | Aqua Dura lens coating | |||||
| Diopter compensation | ±3.5 | |||||
| EHR Range | 10 to 2,800 yards / 10 to 2,600 m ; 10 to 1,200 yards / 10 to 1,100 meters | |||||
| Ballistic output | 10 yds to 875 yards (10 m to 800 m) when using integrated Leica ballistic curves 1-12
± 10 yds to 1,000 yds (10m to 910 m) using custom curve via Leica App 10 yds to 2,800 yds (10 m to 2,600 m) when using Kestrel 5700 Elite |
|||||
| Minimum distance | 10 meters | |||||
| Measuring accuracy | 10 up to 200 yds/m ± 0.5 yds/m
200 yds/m up to 400 yds/m ± 1.0 yds/m 400 up to 800 yds/m ± 2.0 yds/m over 800 yds/m ± 0.5% |
|||||
| Read Outs | LED display with four digits and symbols, ambient light controlled brightness control | |||||
| Eye piece for eyeglass wearers | Yes | |||||
| Eyecup | Turn down rubber eye cup | |||||
| Prism system | Roof prism with phase correction coating P40 | |||||
| Coating | AquaDura lens coating | |||||
| Meter/Yard Selector | Yards/inches or meter/centimeter | |||||
| Measuring Time | Approx. 0.3 seconds | |||||
| Measuring Mode | Scanning mode, single measurements | |||||
| Laser | Eye safe invisible laser according to EN and FDA class 1 | |||||
| Laser Beam Divergence | Approx. 0.5 x 1.2 mrad | |||||
| Interface | Bluetooth 4.1 | |||||
| Smarphone App | Leica Hunting App | |||||
| Minimum Software Requirements for Leica Hunting App | iOS version 9 and Android version 6 | |||||
| Housing | Carbon fiber reinforced plastic | |||||
| Watertightness | Watertight to a depth of 3.2 feet (1 meter) | |||||
| Temperature (function) | -20 to 55 deg C | |||||
| Temperature (storage) | -40 to 85 deg C | |||||
| Battery | 3V Lithium Typ CR2 | |||||
| Battery life | Approx. 1,700 measurements at 68° F (20° C) | |||||
| Weight | 6.7 ounces (189 g) incl. battery | |||||
| Dimensions | 4.5 x 2.25 x 1.25 in (113 x 75 x 34 mm) | |||||
