Pulsar Merger LRF XT50 Thermal Imaging Binocular
The Pulsar Merger LRF XT50 is a thermal imaging binocular that features a laser rangefinder with capability of measuring distances over 1640 yards, enabling users to make quick and informed decisions based on accurate target distance assessments.
One of the standout features of the Merger LRF XT50 binocular comes in the form of a highly sensitive European-made thermal sensor, boasting an impressive <40mK NETD of thermal sensitivity. This thermal sensor captures precise and high-quality images, even under challenging observation conditions with low thermal contrast. Whether you’re observing your prey in the rain, fog, or high atmospheric humidity, the Merger LRF XT50 binocular ensures that even the smallest temperature differences become clearly visible. This cutting-edge technology allows hunters and outdoor enthusiasts to maintain an advantage in identifying targets.
Pulsar Merger LRF XT50 Features
Precise Laser Rangefinder With Over 1640 Yd Range
High Definition Thermal Imaging With 1280×1024 Pixel @ < 40 MK NETD Sensor
Latest Image Processing Algorithms
Fast Aperture 50mm/F1.0 Germanium Lens
Detection Range Up To 2515 YardsTwo Independent Batteries. Up To 6 Hours Of Continuous Work
Specifications
|
Sensor |
1280х1024 @ 12 µm (NETD <40 mK) |
Objective lens |
50mm/F1.0 |
Magnification, x |
2 – 16 |
Field of view (HxV), degrees / m@100m |
17.5/30.7 |
Detection range, yards |
2515 |
Sensor Type |
uncooled |
Resolution, pixels |
1280х1024 |
Pixel pitch, µm |
12 |
NETD, mK |
<40 |
Frame rate, Hz |
50 |
Objective lens |
50mm/F1.0 |
Magnification, x |
2 – 16 |
Field of view (HxV), degrees / m @ 100 m |
17.5/30.7 |
Interpupillary distance adjustment, mm |
63 – 74 |
Eye relief, mm |
15 |
Type |
AMOLED |
Display Resolution, pixels |
1280х960 |
Detection range, yards |
2515 |
Safety class for laser equipment according to IEC 60825-1:2014 |
1 |
Wavelength, nm |
905 |
Max. measuring range, yards |
1640 |
Measurement accuracy, m |
± 1 |
Video / photo resolution, pixel |
1280х960 |
Video / photo format |
.mp4 / .jpg |
Built-in memory, GB |
64 |
Wireless Protocol |
Wi-Fi |
Wireless Standard |
IEEE 802.11 b/g/n/ac (WPA) |
Frequency, GHz |
2.4 / 5 |
Degree of protection, IP code (IEC60529) |
IPХ7 (waterproof) |
Operating temperature range, °F |
-13 – 122 |
Mount, type |
1/4″ socket |
Supported Application |
Stream Vision 2 |
Output voltage, V |
3.7 |
Battery type |
Dual Li-Ion internal + Pulsar APS3 external |
Capacity, mAh |
3200 (external) + 4000 (internal) |
Operating time on battery pack (at t=71°F), h * |
6 |
External power supply, V |
5V, 9V (USB Type-C Power Delivery) |
Body material |
Magnesium alloy |
Dimensions, mm |
197x140x72 |
Weight, lbs |
2 (batteries included) |
