Description

Scalarworks LEAP Magnifier Mount

If you are looking for a state of the art flip side magnifier mount the Scalarworks LEAP Magnifier Mount is for you. The mount is designed for users who want the lightest, strongest, and most compact quick detach mount possible. Engineered to be the lightest Magnifier QD mount, without compromising an ounce of strength. It features a short throw for superior balance and faster magnifier engagement, and has no protruding levers, bolts, or knobs to rap your knuckles, or get caught on clothing, gear, and surroundings. Every Scalarworks LEAP mount is CNC milled from 7075-T6 billet, which has vastly superior mechanical properties to 6061-T6, and is used where ultimate strength and durability outweighs the cost consideration.

 The Scalarworks Ring was designed from the ground up to be stiffer, lighter, and easier to use than split rings. A high strength, precision fitted hinge ensures even pressure around your optic, without requiring the tedious and imprecise setup that split rings do. Twin oversize CNC machined shoulder screws provide even tension and act as structural elements, making the entire ring assembly phenomenally rigid. Each side of the ring is carefully lightened with a curvature continuous scallop that produces a very high strength to weight ratio. The ring is wider than competing designs, providing more surface area to safely and securely hold your optic.

Scalarworks patented ClickDrive quick detach mechanism is intuitive, self adjusting, and completely recoil proof. By decoupling clamping force from vibration resistance, ClickDrive doesn’t need massive amounts of imprecise torque, and is not dependent on unreliable friction. A low profile recessed thumbwheel deflects external impacts, while letting you take the mount off in under 3 seconds, with or without gloves.

Scalarworks LEAP Magnifier Mount Features

State of the Art Flip to Side Magnifier Mounts

Designed for users who want the lightest, strongest, and most compact quick detach magnifier mount possible.

Short Throw

Superior weapon balance. Faster magnifier engagement.

Light Made Right

Engineered to be the lightest Magnifier QD mount, without compromising an ounce of strength.

One Ring

The Scalarworks Ring was designed from the ground up to be stiffer, lighter, and easier to use than split rings.

ClickDrive

Patented ClickDrive quick detach mechanism is intuitive, self adjusting, and completely recoil proof. By decoupling clamping force from vibration resistance, ClickDrive doesn’t need massive amounts of imprecise torque, and is not dependent on unreliable friction. A low profile recessed thumbwheel deflects external impacts, while letting you take the mount off in under 3 seconds, with or without gloves.

Product Manual


Specifications

Materials 7075-T6 Aluminum / 4140H Steel
Finishes Type III Anodizing / Flash Nitride / Black Nitride
Center height over rail 1.42”

1.57”

1.93”

Ring diameter 30mm
Weight 2.87oz
Origin United States of America
Rails MIL-STD-1913 Picatinny*
Aimpoint Magnifiers 3X-C, 3XMag, 3XMag-1, 6XMag-1
Primary Arms Magnifiers 3X, 6X
Fasteners #10-32×0.61″ Nylok treated
Drivers T25 Torx driver bit




Related Items

Additional information

Weight N/A
Height

1.42", 1.57", 1.93"
