Fully multi-coated optics

Wide range of operating temperature, -40 to 122 F


Fogproof, nitrogen purged

IP68 waterproof rating – submergible to 3m/10ft

Rubber armored, single piece 6061-T6 aluminum housing

Red/Green reticle illumination

Scratch resistant lenses

Prismatic optical system

Low power consumption


Reticle Type HS-223
Reticle Color Red/Green
Illuminated Reticle yes
Brightness Setting 5
Finish/Color Matte black
Magnification 3 x
Objective Lens Diameter 24 mm
Eyepiece Diameter 27 mm
Exit Pupil Diameter 8 mm
Eye Relief 2.83 / 72 in/mm
Field of View 10.48 m @100m
Field of View 31.6 ft @100yd
Field of View 6 degree
Diopter Adjustment +3 to -3
Parallax Setting 100 yds
Windage Range of Adjustment 160 MOA
Elevation Range of Adjustment 160 MOA
Windage & Elevation Lock no
MOA Adjustment 1/2 MOA
Maximum Recoil 800 g’s
Battery Type CR2032
Battery Life (high) 200 – (low) 4000 hours
Battery Voltage 3 V
Sunshade no
Nitrogen Purged yes
Shockproof yes
Fog Proof yes
IP Standard IP68 (submergible to 3m)
Body Material Aluminum – 6061 / Rubber
Lens material glass
Lens Coating Fully multicoated AR green
Mount Type Picatinny
Operating Temp,°F/°C -40 to 122 / -40 to 50 F/C
Length 5.9 / 150 in/mm
Width 2.8 / 72 in/mm
Height 3 / 77 in/mm
Weight 17.2 oz


Additional information

Weight 1.1 lbs
Sightmark Reticle Options

HS-223, HS-300
