Sightmark Wraith 4K Max 3-24×50 Digital Scope


Out of stock

Want to be notified when this product is back in stock?

SKU: SM18030 Category: Tag:

Sightmark Wraith 4K Max 3-24×50 Digital Scope

The Sightmark Wraith 4K Max Digital Scope is a combination of technology, power and precision. It uses an enhanced ultra high definition 4000×3000 digital CMOS sensor to detect objects up to 300 yards away in low light conditions. In daylight the detection range is even further. The Wraith features a sharp 1280×720 display resolution that delivers crystal clear imaging, and a 3-24x digital magnification that gives users the versatility to adjust as needed. The 850nm IR illuminator features 90 minutes of operating time on max and its night vision mode and daytime color mode offer crisp, vibrant views. Its aluminum housing is IPX5 water resistant. The scope boasts built in UHD 4K video recording with audio, 10 reticle options and a rechargeable batter that provides up to 8 hours of power.

Sightmark Wraith 4K Max 3-24×50 Digital Scope Features

Enhanced ultra high definition 4000×3000 sensor

Crystal clear 4K digital imaging

300 yard detection range

Night vision mode

Daytime color mode

Sharp 1280×720 HD full color display

3-24x magnification

Detachable 850nm IR LED illuminator

Built in video recording

10 reticle options in 9 colors

Up to 8 hour run time on an internal rechargeable battery

Additional weaver rail for accessories

4 weapon profile saves

Included in Package

IR flashlight

Daytime lens filter

Objective lens cover

Fixed picatinny mount

USB cable

User manual

How to Update Sightmark Wraith 4K Max Firmware


Type of Sensor CMOS Sensor
Sensor Resolution, Pixels 4000×3000
Display Type LCOS
Display Resolution, Pixels 1280×720
Built In Video Recorder Availability Yes
Maximum Memory Card Supported, Gb 256
Format of Video Clip MP4
Resolution of Video Clip 4K/1080/720
Format of Photo Files JPEG
Resolution of Photo Files 1080/720
Magnification 3 – 24 x
Diameter, Lens, mm 50 mm
Digital Zoom 1 – 8 x
Lens Focus, mm 60 mm
Relative Aperture, D/f’ 1.2
Field of View, m @ 100m 10.5
Field of View, ft @ 100yd 31.5
Minimum Focusing Distance, ft/m 16.4
Eye Relief 2.7 / 69 (in / mm)
Diopter Adjustment +/- 5
Emitter LED
IR Wavelength 850nm
Equivalent IR Power, mW 2,500
Battery Life (with IR) 90 minutes on max
Night Vision Detection Range 300 / 274 (yd / m)
Battery Life, Hours 5 hours recording / 8 hours no wifi and no recording
External Power Supply 5V via USB
Windage & Elevation Click Value .3 MOA
Elevation Range of Adjustment 60 MOA
Windage Range of Adjustment 227 MOA
Number of Preloaded Reticles 10
Colors Black, white, red, blue, green, cyan, orange, yellow, magenta
Body Material Aluminum
Accessory Rail Mount Picatinny
Operating Temperature – 4 to 140 / – 20 to 60 (F / C)
Waterproof Rating IPX5 – water resistant
Shockproof Yes, 3ft
Maximum Recoil .308
Length 12 / 304.8 (in / mm)
Width 1.875 / 63 (in / mm)
Height 3 / 75 (in / mm)
Weight, oz 34.6 oz
