Steiner DBAL D2 Dual Beam Aiming Laser w/ IR LED Illuminator


Available Options:

Steiner DBAL D2 Dual Beam Aiming Laser

Manufactured with high definition, aspherical telescopic lens technology, the Steiner DBAL D2 features a 2° to 30° adjustable illumination beam. This highly collimated beam greatly improves night vision performance and offers an eye safe means of illuminating distances greater than 1000 m. The visible green laser and IR laser are co aligned making sighting in an easy process. The DBAL D2 works best with up to date night vision products.

DBAL D2 Features

Fully Adjustable Windage and Elevation

Quick Release HT Mount (Picatinny Rail)

Visible green laser

IR Aiming Lasers

IR LED Illuminator

Powered By: One CR 123A Battery

Includes Remote Cable Port

Activation / Mode Selector SwitchIntegrated Activation Switch

Available in Black (9001) and Desert Sand (9002)

To contact Steiner click here »


Visible Green Laser Wavelength 532 nm
IR Laser Wavelength 850 nm
IR Illuminator Wavelength 850 nm LED
Visible Green Laser Divergence < 0.8 mRad
IR Laser Beam Divergence < 0.8 mRad
IR Illuminator Beam Divergence 2° to 30°
Range/Visibility (Night/Day)* Visible Green Laser 750 m / 15 m
Range/Visibility (Night/Day)* IR Laser > 250 m
Range/Visibility (Night/Day)* IR Illuminator ≤ 1,000 m
Temperature -20° C to +65° C
Battery CR 123A
Battery Life (mode dependent) > 3 hours
Material Aircraft Aluminum
Color Desert Sand/ Black
Weight (with battery) 12.5 oz.
Dimensions 3.95 (L) x 3.37 (W) x 1.59 (H)
Waterproof Submersible to 5 m
Mount QD HT Mount
Windage and Elevation Adjustment Yes
Activation Switch Integrated Push Button
Remote Cable Pressure Pad Yes
Warranty 3 Years
Special Features Co-aligned Visible & IR Aiming Lasers

Export is strictly prohibited without a valid export license issued by the U.S. Department of State, Office of Defense Trade Controls, prescribed in the International Traffic in Arms Regulation (ITAR), Title 22, Code of Federal Regulations, Parts 120-130.
