Trijicon Compact ACOG TA44 1.5x16s
The Trijicon Compact ACOG TA44 1.5x16s scope is a fixed magnification riflescope that features an illuminated reticle pattern for use in any light conditions. The dual illumination provides both fiber optics and tritium as sources of battery free illumination. The fiber optics use ambient light to automatically adjust the brightness level and contrast of the reticle to available light conditions. While the tritium phosphor lamp glows in low light conditions. The body of the scope is constructed of 7075-T6 aircraft grade aluminum making it nearly indestructible.
High Height Body
The high height body provides weapons like the M16/M4 with excellent fire control capability. Targets are easier and quicker to acquire through the 1.5×16 models because of the larger field of view (7.4 degrees) and eye-friendly design.
Low Height Body
The Mini ACOG’s low height body design allows for the lowest possible mounting configuration. This achieves the desirable height above bore for the AK and other select firearm models with lower cheek welds.
Trijicon Compact ACOG TA44 1.5x16s Features
Tritium/fiber optic illuminated reticle
Choice of low or high profile
Fixed power design allows for minimal moving parts to create a nearly indestructible sighting system.
“Both eyes open” shooting using The Bindon Aiming Concept (BAC) allows for improved situational awareness.
The quality of the glass and multi coated lenses maximize light-gathering capabilities and clear field of view with zero distortion.
No other magnified optic has been used more in combat than the ACOG.
Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements.
Exceptional waterproof performance that exceeds military standards. Dry nitrogen filled to eliminate fogging. This optic is tested to withstand and perform in extreme cold and heat with dry nitrogen filled housing that mitigates fogging.
|Objective Size||16 mm|
|Reticle Pattern||Circle Dot
RTR 9mm PCC
|Day Reticle Color||Red
|Night Reticle Color||Red
|Bindon Aiming Concept (BAC)||Yes|
|Illumination Source||Fiber Optics and Tritium|
|Power Source||Fiber Optics and Tritium|
|Adjustment||2 clicks per in @100 yards|
|Eye Relief||2.4 in|
|Exit Pupil||0.42 in|
|Field of View||7.4°|
|Field of View||39 ft. @ 100 yards|
M16/AR15 Carry Handle Base
Q-LOC Technology Mount
|Housing Material||Forged Aluminum|
|Length x Width x Height||High – 4 in x 1.6 in x 2.1 in
Low – 4 in x 1.6 in x 1.7 in
