AGM Asp Micro TM160
The AGM Asp Micro TM160 is an unbelievable unit at an unbelievable price. This handheld thermal monocular is equipped with a 160×120 infrared detector and a 720×540 LCOS display. It supports functions of observation, highest temperature target tracking, distance measurement, Wifi hot spot, and so on. The high sensitivity built in thermal detector gives you with clear view even in total darkness. The monocular is mainly for scenarios such as patrolling, law enforcement, search and rescue, and Hunting
AGM Asp Micro TM160 Features
Distance Measurement
The device realizes distance measurement function after marking the top and bottom of target, and input the target height.
Hot Spot Mark
Detects and marks the hot spot of highest temperature.
Mode Switch
Device supports pallet switch and distance measurement.
Storage
Built in memory for video recording and snapshots.
Digital Zoom
Device supports 1×, 2×, and 4× digital zoom.
Wifi Hot Spot
Device can take snapshots, record videos, and set parameters via APP after being connected to your phone.
160×120 resolution, high sensitivity detector
Adaptive AGC, DDE, 3D DNR
720×540 resolution LCOS display
Built in rechargeable Lithium battery
Wifi hot spot
Type C interface
Specifications |
||||||
| Digital Magnification | 0.5x – 2x | |||||
| Detector type | Vanadium Oxide Uncooled Focal Plane Arrays | |||||
| Response Waveband | 8μm to 14μm | |||||
| FFC (Flat Field Correction) | Auto, Manual, External Correction | |||||
| Highest Temperature Spot Tracking | Yes | |||||
| Standby Mode | Yes | |||||
| Refresh rate | Sensor 25 Hz / OLED 50 Hz | |||||
| Aperture | F1.1 | |||||
| Resolution | 160×120 | |||||
| Recognition | (Vehicles: 1.4×4.0m) – 153m/yd (Humans: 1.8×0.5m) – 50m/yd | |||||
| Detection Range | (Vehicles: 1.4×4.0m) – 611m/yd (Humans: 1.8×0.5m) – 250m/yd | |||||
| Identification Range | (Vehicles: 1.4×4.0m) – 76m/yd (Humans: 1.8×0.5m) – 25m/yd | |||||
| NETD | less than 35 mk (@25°C), F#=1.1 | |||||
| Lens (focal length) | 6.2 mm | |||||
| Field of view (H × X) | 15.61° × 11.74° (H × V) | |||||
| Digital zoom | 2×, 4×, 8× | |||||
| Display | 720×540, 0.2 inch, LCOS | |||||
| Storage | Built-in memory module (8 GB) | |||||
| Record Video | On-board video recording | |||||
| Capture Snapshot | Yes | |||||
| Battery Type | Built-in rechargeable Lithium battery | |||||
| Wi-Fi | Yes | |||||
| Battery Operating Time | Up to 10 hours | |||||
| Battery Capacity Display | Yes | |||||
| Power supply | 5 VDC/2 A, 1.5 W | |||||
| Operating Temperature Range | -20°C to 55°C (-4°F to 131°F) | |||||
| Weight | 270 g (0.6 lb) | |||||
| Overall Dimensions | 161 × 61 × 57 mm (6.3 × 2.4 × 2.2 in) | |||||
| Protection Level | IP67 | |||||
| Magnification | 0.5x | |||||
