Leupold Mark 4 20-60x80mm Spotting Scope w/ TMR Reticle


Only 2 left in stock

SKU: 110826 Categories: , , Tags: , , ,

Leupold Mark 4 20-60x80mm Spotting Scope w/ TMR Reticle

The Leupold Mark 4 20-60x80mm spotting scope was designed with a TMR reticle. This will allow for the brightness and clarity necessary for positive target identification no matter the conditions. It features more magnification than its 12-40x60mm counterpart. Built to survive shock, blows, drops and impacts, it’s not only tough, it’s also 100% waterproof and fogproof.

The scope boasts Leupold’s Professional Grade Optical System, it offers unmatched light transmission that is designed to outperform in the most challenging lighting conditions. Its industry leading glare reduction provides a clear image in harsh, direct light, while the resolution and clarity will meet the demands of any professional guide or shooter in the field.

Countless military sniper teams have trusted the Mark 4 tactical spotting scope. You can depend on it, too. This rugged spotting scope is designed, machined and assembled in the USA and features a guarantee for life.

Leupold Mark 4 Features

Professional Grade Optical System

Leupold’s Professional Grade Optical System offers unmatched light transmission that’s designed to outperform in the most challenging lighting conditions, industry leading glare reduction for a clear image in harsh, direct light, and the resolution and clarity that professional guides and shooters demand in the field.

Folded Light Path

Folded light path technology helps achieve a compact, lightweight design.

Diamond Coat 2

Exterior lens surfaces are treated with Diamond Coat 2, an ion assist lens coating, for higher light transmission and the greater level of abrasion resistance Leupold has ever offered. Diamond Coat 2 has the additional advantage of assisting in light transmission, for greater brightness, clarity and contrast, and will prove its worth in the wildest places on earth.

Fully Multi Coated Lens System

Leupold’s fully multi coated lens system ensures maximum brightness for clarity, contrast and color fidelity.

Tripod Ready

A built in 1/4-20 rotatable tripod adapter port makes it easy to mount to a tripod.

Magnesium Housing

Lightweight but tough as nails, a rugged magnesium housing protects the optic during fast paced action.

Waterproof and Fogproof

Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures and elevation changes, so the internals of the optics stay moisture free and crystal clear for life.

Extreme Climate Exposure

Leupold makes sure that their optics perform at the highest level in the harshest conditions by ensuring they will survive from -40 degrees Fahrenheit all the way up to 160 degrees Fahrenheit.

Guaranteed for Life

Built for a lifetime of performance – if at any time your spotter scope doesn’t perform, Leupold will repair or replace it for free – whether you’re the original owner or not.

TMR Reticle

Expands on existing MIL Dot Reticle design

Utilizes harsh marks instead of dots for increased ranging precision

1 MIL is approximately 3.6 inches at 100 yards

Hash marks are spaced 0.5 MIL apart, transitioning to 0.2 MIL spacing on the outer edges

Not caliber specific

MIL based systems are the current military standard

Front (first) focal plane

Product Manual

Tactical Milling Manual


Reticle FFP TMR (Spotting Scope)
Tripod Included No
Eyepiece Style Straight
Length (in) 15.5
Weight (oz) 61.8
Magnification Max 60
Magnification Min 20
Objective Diameter (mm) 80
Linear FOV Low Mag (ft@1000yds) 121
Linear FOV High Mag (ft@1000yds) 42
Angular FOV Low Mag (Degrees) 2.3
Angular FOV High Mag (Degrees) .8
Eye Relief Low Mag (mm) 30
Eye Relief High Mag (mm) 30
Exit Pupil Low Mag 4.1
Exit Pupil High Mag 1.3
Close Focus Distance (ft) 75
