Description

Leupold RX FullDraw 3 Rangefinder

The Leupold RX FullDraw 3 Rangefinder was designed to give bowhunters an advantage to tag out. With 1/2 yard, and angle compensated accuracy, there is no second guessing the distance. The RX FullDraw 3 features Leupold’s unique Trophy Scale, so you can easily gauge an animal’s size while you’re ranging it to make sure it’s the shooter you’re looking for.This extremely fast rangefinder reaches out to 1,300 yards, so even if you’re too far to take the shot, you’ll know how much distance you need to close in order to seal the deal.

Leupold RX FullDraw 3 Rangefinder Features

Rangefinder – Bow Mode

Bow mode uses the distance and the angle of a shot to calculate a ballistic equivalent to the target for more accurate uphill and downhill archery shots.

Selectable Reticles

Offers a variety of reticles to choose from to fit any use or preference

Trophy Scale

Trophy Scale generates marks in the rangefinder’s display, so you can accurately determine the animal’s rack width or height when you range it.

Product Manual


Specifications

Finish Green/Black
Magnification 6
Tripod Compatible (1/4-20) No
Archery Angle Compensation Bow Mode
True Ballistic Range – Wind (TBR-W) No
True Ballistic Range (TBR) No
Horizontal Distance (TRIG-H) No
Archer’s Advantage No
True Golf Range (TGR) No
Line of Sight (LOS) No
Flight Path No
Last Target Mode No
Prism Lock No
Battery Type CR2
Display Color LCD (Black Display)
Length (in) 4
Width (in) 1.3
Height (in) 2.5
Weight (oz) 7
Objective Diameter (mm) 23
Linear FOV (ft@1000 yd) 315
Angular FOV (Degrees) 6
Eye Relief (mm) 14
Min Diopter (dpt) -3
Max Diopter (dpt) 3
Light Transmission (%) 65
Battery Life (Actuations) >5000
Accuracy to 125 (yd) .5
Accuracy to 1000 (yd 2
Accuracy above 1000 (yd) % .5%
Max Range – Deer (yd) 900
Max Range – Trees (yd) 1100
Max Range – Reflective (yd) 1300
Max Range – Golf Flag (yd) 0
Min Range (yd) 6
Laser Classification IEC 3R
