Steiner DBAL A3 Dual Beam Aiming Laser

The Steiner DBAL A3 Dual Beam Aiming Laser-Advanced 3 is the first eye safe IR laser pointer, IR illuminator and green laser pointer in a single compact unit. Features an adjustable IR illuminator for better illumination at longer ranges, dual activation switches and high and low power modes.

The DBAL A3 class 1/3R Civilian, based on the standard issue DBAL A3 for U.S. warfighters, brings the latest advances in IR and laser technology to the civilian market with its dual beam reliability for extreme accuracy in low and no light maneuvers. In addition, the DBAL A3 is the first to feature new defocused adjustable IR illumination technology to enable both midrange and close quarter target acquisition.

Steiner DBAL A3 Dual Beam Aiming Laser-Advanced 3 Features

Visible Green Laser

IR Laser

IR Illuminator

Fully Adjustable Windage and Elevation

Dual remote cable ports

Single laser activation switch,

Low profile windage and elevation adjusters

Mounting holes for a flip up front sight, sub miniature red dot sight or a MIL SPEC 1913 top rail.

6061 T6 Aircraft Aluminum, MIL SPEC Type III hard coat anodized case

To contact Steiner click here »


Visible Green Laser Wavelength 532 nm
IR Laser Wavelength 835 nm
IR Illuminator Wavelength 835 nm
Visible Red or Green Laser Beam Divergence <0.8 mRad
IR Laser Beam Divergence <0.8 mRad
IR Illuminator Beam Divergence 95-195mRAD (non LED)
Visible Green Laser Visibility Range Night and Day 750 m,  15 m
IR Laser Visibility Range Night and Day >250m
IR Illuminator Visibility range Night and Day ≤1000 m
Temperature -10° C to +65° C
Battery CR 123A
Battery Life (mode dependent) > 3 Hours
Material Aircraft Aluminum
Color Black, Desert Sand
Weight (with battery) 8 oz.
Dimensions 3.5 (L) x 2.75 (W) x 1.59 (H)
Waterproof Submersible to >5 m
Mount QD HT Mount
Windage and Elevation Adjustment Yes
Activation Switch Integrated Push Button
Remote Cable Pressure Pad Yes
Warranty 3 Years
Special Features Dual Remote Cable Ports


Export is strictly prohibited without a valid export license issued by the U.S. Department of State, Office of Defense Trade Controls, prescribed in the International Traffic in Arms Regulation (ITAR), Title 22, Code of Federal Regulations, Parts 120-130.

Similar Products

More from Steiner

Additional information

Weight 0.5 lbs
Case Color Options

Black, Desert Sand
