Trijicon ACOG 3.5×35 BAC Scope / 9.0 MOA RMR Type 2 Combo
The Trijicon ACOG 3.5×35 BAC was selected as the U.S. Marine Corps Squad automatic weapon Day Optic (SDO). The SDO mounts to M249 light machine-gun to assist in target detection, recognition and identification. It provides the user with quick target acquisition at close quarter distances or when vehicular mounted. Rugged, reliable housing design allows for the optic to be shock resistant, waterproof and practically indestructible. The ACOG 3.5×35 features a Red Horseshoe Dot Reticle and is paired with a 9.0 MOA RMR Type 2.
Trijicon ACOG 3.5×35 BAC Scope / 9.0 MOA RMR Type 2 Combo Features
Always On, Always Ready
Most ACOG models are battery free, featuring a tritium/fiber optic illuminated reticle that automatically adjusts the brightness based on available light.
Several ACOG models are designed with a user adjustable brightness setting powered by a single AA battery. The 3.5×35 LED and 4×32 LED models both offer six adjustable brightness settings.
Rugged, Reliable Housing Design
Fixed power design allows for minimal moving parts to create a nearly indestructible sighting system.
“Both Eyes Open” Design
“Both eyes open” shooting using Trijicon’s Bindon Aiming Concept (BAC) feature allows for improved situational awareness.
The quality of the glass and multi coated lenses maximize light gathering capabilities and clear field of view with zero distortion.
Exact Target Distances & Holds
Most ACOG models feature a bullet drop compensating and target ranging reticle for decisive aiming.
No other magnified optic has been used more in combat than the ACOG.
Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements.
Exceptional waterproof performance that exceeds military standards. Dry nitrogen filled to eliminate fogging. This optic is tested to withstand and perform in extreme cold and heat with dry nitrogen filled housing that mitigates fogging.
Trijicon ACOG 3.5×35 BAC Scope / 9.0 MOA RMR Type 2 Combo Includes
9.0 MOA RMR Dual Illuminated Amber Dot Sight (RM05)
LaRue Tactical Quick Detach Mount
Tenebrax killFlash Anti-Reflective Device
Set of Flip Up Lens Caps
Lanyard Assembly for Adjuster Caps (TA71E)
Trijicon Logo Sticker (PR15)
|Length x Width x Height||8.7 in x 2.1 in x 2.9 in
(220.98 mm x 53.34 mm x 73.66 mm)
|Objective Size||35 mm|
|Reticle Pattern||Horseshoe Dot|
|Day Reticle Color||Red|
|Night Reticle Color||Red|
|Bullet Drop Compensating (BDC)||Yes|
|Bindon Aiming Concept™ (BAC)||Yes|
|Illumination Source||Fiber Optics & Tritium|
|Power Source||Fiber Optics & Tritium|
|Adjustment||.1 mils per click @100 yards|
|Eye Relief||2.4 in.
|Exit Pupil||0.39 in.
|Field of View (degrees)||28.9°|
|Field of View (feet)||4 ft. @ 100 yds.
(1.33 m @ 100 m)
|Mount||Levered Quick Detach Mount|
|Housing Material||Forged Aluminum|
