Description

NVison HALO XRF Thermal Imaging Scope

The NVison HALO XRF Thermal Imaging Scope is designed with state of the art BAE thermal imaging CORE. The core features a BAE of 640×480, 12 um, and 60 Hz. It has a digital zoom of 2x, 4x and 8x. It features an integrated laser range finder, onboard video recording, WIFI connectivity, 8 reticles options, and is available with 50mm objective lens. The HALO-X is powered by two rechargeable 18650 batteries that provide 7 hours of run time. The Thermal Imaging scope is built in the USA.

NVision HALO XRF Thermal Imaging Scope Features

Optical

BAE 640 x 480, 12 um, 60 Hz thermal imaging core

Upgraded 50 mm F1.1 Germanium objective lens

Field of View 9° x 7°

640 x 480 B&W OLED Display

Digital Zoom: 2x, 4x, and 8x

Built in Video and Audio Recording

HALO-XRF eliminates the need for external recorders. Pixel accurate 60 Hz videos are internally captured and stored for later transfer to the user’s PC via USB connection.

Streaming

The streaming feature permits the user to stream videos over the WiFi connection and possibly broadcast the hunts in real time to Youtube, Facebook, or any other social media if it is still allowed and available.

Laser Range Finder (HALO-XRF)

HALO-XRF features a built-in laser range finder with a range of up to 1,000 yards/meters.

Rechargeable 18650 Batteries

HALO-XRF operates on two rechargeable 18650 batteries, providing up to 7 hours of run time (at room temperature).

Zoom Sensitive Zeroing

Reticle movement steps are zoom dependent, which allows for the most precise zeroing.

Reticles

Eight reticle choices with two Mil Dot reticles.

USB-C Connector

Standard USB-C type cable is used for user software updates, downloading videos and still images, or powering up the HALO-XRF with an external 5V (USB) power source


Specifications

Sensor Pixel Pitch 12 um
Resolution 640 x 480
Refresh Rate 60 Hz
Lens 50mm F1.1
Focus Fixed
Digital Zoom 1x/2x/4x/8x
Magnification 3.5x
Display Type OLED 640×480 B&W
Power two 18650 batteries
Remote power USB 5.0V
External connector Waterproof USB-C
Calibration (NUC) Manual
Detection range 2020 yards
Recognition range 726 yards
Identification range 380 yards
Size 8.9 x 4.1 x 3.4 inches
Weight 41.5 oz






Related Items

Additional information

Weight 2.6 lbs
