| Size L x W x H |
207 x 56 x 56 mm(8.1 x 2.2 x 2.2 in) |
| Weight |
235 g(8.3 oz) |
| Dot Size |
2 MOA |
| Magnification |
1X – No Magnification |
| Night Vision Device (NVD) Compatible |
No |
| Transmission |
Average 60% in the range 420 – 700 nm |
| Eye Relief |
Unlimited |
| Mounting Solution |
Not Included |
| Operating Principle |
Reflex collimator sight – red dot sight |
| Diode |
LED (Light Emitting Diode) Totally eye safe |
| Dot Color |
Red |
| Dot Intensity |
Visible against a background luminance of 0.1 to 55 000 lx |
| Light Source Wavelength |
650 nm red light |
| Optical Coating |
Anti reflex coating all surfaces and multilayer coating objective lens |
| Clear Aperature |
25mm(1.0 in) |
| Parallax |
Parallax free – no centering required |
| Battery Life |
50,000 h at daylight setting 7 (room temperature) |
| Battery Type |
CR2032, 3V, Lithium |
| Power Switch |
Push Buttons |
| Daylight (DL) Settings |
12 |
| Material Housing and Tube |
High Strength Aluminum |
| Surface Finish Housing |
Anodized, Semi-Matte |
| Color Housing |
Black |
| Tube Diameter |
30 mm(1.2 in) |
| Lens Covers |
Flip-up Lens Covers, Transparent |
| Material Lens Covers |
Thermoplastic Elastomer (TPE) |
| Adjustment |
1 Click = 20 mm at 100 m(0.7 in at 100 yds) |
| Submersible |
1 m(3 ft) |
| Laser |
No Laser Emission |
| Radioactive Material |
None |
| Temperature Range Operation |
– 30°C to + 60°C(- 20°F to + 140°F) |
| Temperature Range Storage – Operable after a temperature shock between |
– 51°C to + 71°C(- 60°F to + 160°F) |
| Temperature Shock Operable after a temperature shock between |
– 30°C and + 60°C(- 22°F and + 140°F) |
| Humidity – Operable during and after Humidity. Limits |
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic |
| Shock – Operable before and after shock. Limits |
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction. |
| Vibration – Withstands vibration. Limits: Withstands Vibration. Limits |
Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction. |
| Chemical Resistance |
Withstands occasional contamination by weapons cleaners, lubricants, fuels and insect repellents. |
| Mounting Solution |
Not Included |
| Max Ring Width |
30 mm(1.2 in) |
| Max Distance Between Rings |
137 mm(5.4 in) |
