The IR-PATROL™ offers a high-performance thermal core, along with the industry-leading 640×480 VGA OLED Micro Display, to give the user optimal detection capabilities and clear, detailed imagery they can trust to conquer darkness.
SUPERIOR PROCESSING POWER
VERSATILE BY DESIGN
With the IR-PATROL M250, you can take advantage of the lightweight design and fast, 60 Hz frame-rate system that is optimized for helmet mounting. The optional Wilcox® adapter kit makes it easy to fit the system on most helmets.
THUMBSTICK SYSTEM CONTROLLER
AFOCAL MAGNIFIER LENS MULTIPLIERS
MAXPOL POLARITY WHITE HOT/ BLACK HOT
The IR-PATROL comes with an easy-tocontrol polarity mode that lets you switch between three levels of white hot and three levels of black hot. Why limit yourself to one setting? With low, medium and high levels, you can pick your perfect mode.
|APPLICATION||Handheld / Tripod Mounted|
|SENSOR MICRON||12 μm|
|SENSOR TYPE||Vox Vanadium Oxide|
|FRAME RATE||30 Hz|
|DISPLAY TYPE||Digital OLED|
|THERMAL SENSITIVTY||< 50mK|
|SPECTRAL RESPONSE||8-12 MICRONS|
|FIELD OF VIEW||22°|
|MAGNIFICATION / E-ZOOM||1x Optical / 8x Digital|
|OBJECTIVE LENS||19mm f/1.2|
|BATTERY TYPE||CR123 Lithium|
|BATTERY LIFE||Approx. 2 hours / battery|
|ENVIROMENTAL||-40°C to +55°C Operating -45°C to +75°C Storage|
|WEIGHT||16 oz. / 454g|
|DIMENSIONS||5.95 in. x 2.0 in. x 2.95 in.|
|MOUNTING KIT||¼-20 Interface|
|POLARITY / E-ZOOM||Yes|
Trijicon Products are subject to export controls administered by the U.S. Department of Commerce or the U.S. Department of State and require an export license to be shipped outside of the United States. Export or re-export without prior authorization from the U.S. Government is prohibited. For this reason, we only sell directly to established distributors, who have provided the necessary information and documentation required for proper authorization to export.
For additional information, please contact the Trijicon Export Compliance Team by calling 1-248-960-7700.
